Tektronix IsoVu TIVP Series User Manual page 36

Maximum Non-Destructive
Differential Voltage
Common mode voltage range
Common mode input impedance (Typical)
Input resistance
Input capacitance
DC Gain accuracy
Differential DC gain
accuracy
System noise (rms)
Propagation delay
2 meter cable
10 meter cable
Derated with frequency; refer to the Maximum differential input voltage vs. frequency derating graph in the Specifications section of the TIVP Series IsoVu
2
Measurement System User Manual.
3
The capacitance between the sensor head and a reference plane. The sensor head is placed six inches (15.25 cm) above the reference plane.
TIVP Series IsoVuTM Measurement System User Manual
Sensor tip
cable
TIVPSQ100X 160 dB*
TIVPWS500X 160 dB*
TIVPMX1X
Sensor tip cable
SMA Input (50 Ω mode)
SMA Input (1 MΩ mode)
TIVPMX10X
TIVPMX50X
TIVPSQ100X
TIVPWS500X
TIVPMX1X
60 kV peak
Galvanically isolated through the fiber optic connection
<2 pF
3
<2%
Sensor tip cable ±20 mV range
SMA Input (50 Ω
mode)
SMA Input (1 MΩ
mode)
TIVPMX10X
TIVPMX50X
TIVPSQ100X
TIVPWS500X
18.3 ns
57.3 ns *
DC 1 MHz 100 MHz 200 MHz 500 MHz 1 GHz
100 dB* 70 dB*
100 dB* 60 dB*
160 dB* 145 dB* 100 dB*
Vpk (DC + peak AC)
5V RMS
100 Vpk
250 Vpk
300 Vpk*
600 Vpk*
3300 Vpk*
5 V RMS (50 Ω), 100 Vpk (1 MΩ)
±320 mV range
(most sensitive)
0.43 mV rms 1.46 mV rms
0.43 mV rms 1.46 mV rms
4.3 mV rms 14.6 mV rms
21.5 mV rms* 73 mV rms*
43 mV rms* 146 mV rms*
215 mV rms* 730 mV rms*
Reference information
57 dB* 39 dB* 30 dB*
48 dB* 33 dB* 25 dB*
100 dB* 100 dB* 90 dB*
2
±5 V range (widest
range)
48 mV rms
48 mV rms
480 mV rms
2.4 V rms*
4.8 V rms*
24 V rms*
36
