ATM OAM Settings Menu

ATM OAM Settings
Main Menu\ATM Circuit Management\ATM OAM Settings\
The ATM OAM Settings menu (see
OAM settings and to test the Inband channel PVC for an ATM fed system.
TID: HSVL00001
Unacknowledged Alarms: None
1. DSLAM OAM Loopback Location ID :
2. DSLAM OAM State
3. Inband OAM Loopback Test
The ATM OAM Settings menu options are shown in
Option Description
1 DSLAM OAM Loopback
Location ID
2 DSLAM OAM State
3 Inband OAM Loopback Test
61179621L1-5C
Figure
ATM OAM Settings
Selection :
'?' - System Help Screen

Figure 5-27. ATM OAM Settings Menu

Table 5-25. ATM OAM Settings Menu Options

Function
This is option is used to enter the loopback location ID
for the Total Access 1224. The remote loopback location
ID is in hexadecimal 16 byte format.
This option is used to toggle the Total Access 1224 OAM
state between Disabled and Enabled.
This option displays the
Menu"
5-27) is used to provision the Total Access 1224
Total Access 1224
FFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF
: Disabled
Table 5-25.
on page 5-42.
Menu Descriptions
"Inband OAM Loopback Test
5-41
