Adsl Ports Status Screen; Figure 5-109. All Adsl Ports Status Screen - ADTRAN NetVanta 1224 Installation And Maintenance Practice

ADSL Ports Status Screen

ADSL Ports Status
Main Menu\DSL Menus\Status\ADSL Ports Status\
An example of the report returned from selecting the ALL ADSL Ports Status option is shown
in Figure 5-109.
TID: HSVL00001
Unacknowledged Alarms: None
Link
State
1. Down
2. Down
3. Down
4. Down
5. Down
6. Down
7. Down
8. Down
9. Down
10. Down
11. Down
12. Down
61179621L1-5C
ADSL Ports Status
Rate: D/U Margin: D/U
Mode (kbps) (dB)
'n' for next page
'?' - System Help Screen

Figure 5-109. All ADSL Ports Status Screen

Total Access 1224
Shelf = Host
Link Rate: D/U
State Mode (kbps)
13. Up ADSL2+ 11996/ 883
14. Down
15. Down
16. Down
17. Down
18. Down
19. Down
20. Down
21. Down
22. Down
23. Down
24. Down
Menu Descriptions
MM/DD/YY HH:MM
Margin: D/U
(dB)
23/ 6
