Specifications - Microtek Medi-6000 Plus User Manual

Specifications

Scanner Type
Model Type
Light Source
Scanning Modes
Resolution
Scanning Area
Film Size
Lamp Life
Product Life Cycle
Interface
Dimensions (L x W x H)
Weight
Voltage
Power Consumption
Environment
50 Medi-6000 Plus User's Manual
Important
Specifications, software bundles, and accessories are subject to change without notice.
Not responsible for typographic errors.
Sheet feed film digitizer
MSS- 600XU2LAF
LED (Light Emitting Diode)
Grayscale in a single scanning pass
Input:
8-bit grayscale (Approx. 256 shades of gray)
16-bit grayscale (Approx. 65,536 shades of gray)
Output:
8-bit grayscale (Approx. 256 shades of gray)
12-bit grayscale (Approx. 4,096 shades of gray)
16-bit grayscale (Approx. 65,536 shades of gray)
600 dpi
14" x 35" (355.6 mm x 889 mm)
Min: 2.5" x 2.5" (63.5 mm x 63.5 mm)
Max: 14" x 35" (355.6 mm x 889 mm)
1,000,000 scans at 300 dpi
100,000 scans or 5 years
Hi-Speed USB (USB 2.0)
10.2" x 18.7" x 9.3"
(260 mm x 474 mm x 235 mm)
19.82 lbs. (9 kg)
AC 100V to 240V, 47-63 Hz
1.5A Max (Input)
54.9 W (Max)
Operating temperature: 50° to 104°F (10° to 40°C)
Relative humidity: 20% to 85%
Storage temperature: 14° to 140°F (-10° to 60°C)
Relative humidity: 20% to 95%
Atmosphere pressure: 70-101.3 kPa (700-1013 hPa)
Altitude: <=2000 m
