Specifications - Microtek MIL-800XL Plus User Manual

Specifications

Type
Image Sensor
Lamp Source
Scanning Modes
Resolution
Dynamic Range
Scanning Area
Product Life Cycle
Interfaces
Dimensions (L x W x H)
Weight
Voltage
Power Consumption
Environment
36 MII-800XL Plus User's Manual
Important
Specifications, software bundles, and accessories are subject to change without
notice. Not responsible for typographic errors.
Desktop flatbed film digitizer
CCD (Charge-Coupled Device)
LED
Grayscale in a single scanning pass
16-bit grayscale (Approx. 65,536 shades of gray)
8-bit grayscale (Approx. 256 shades of gray)
Optical: 3200 dpi (H) x 6400 dpi (V)
4.7 Dmax (Max.)
Transparent: 12" x 15.9" (305 mm x 404 mm)
100,000 scans or 5 years
Hi-Speed USB (USB 2.0)
24.7" x 14.8" x 7.1"
(627.5 x 375.9 x 180.5 mm)
35.4 lbs (16.1 kg)
AC 100V to 240V, 47-63 Hz, 1.5A Max.
54.9 W (Max.)
Operating temperature: 50° to 104°F (10° to 40°C)
Relative humidity: 20% to 85%
Storage temperature: 14° to 140°F (-10° to 60°C)
Relative humidity: 20% to 95%
