AT-1610 Head Crimp Tool
Air Powered
Crimp
Tool Head
FEATURES
Quick-change tool head for the 19279-0001 (AT-200)
A precision user-friendly terminal locator stop holds terminals in the proper crimping position
SCOPE
Products: Nylon closed end connectors 10 - 18 AWG. This tool head is intended for use in the 19279-0001 (AT-
200) either hand held or with optional bench adapter 19078-0307 (ATBA) and foot switch.
Testing
Mechanical
The tensile test, or pull test, is a means of evaluating the mechanical properties of the crimped connections.
The following charts show the UL specifications for various wire sizes. The tensile strength is shown in pounds
and indicates the minimum acceptable force to break or separate terminal from the conductor. On this style
product, only the reading from the smallest wire AWG is used. See Chart 1.
The following is a partial list of the product part numbers and their specifications that this tool is designed to run.
We will be adding to this list and an up to date copy is available on www.molex.com.
Terminal No.
19160-0002
19160-0003
19160-0004
19160-0006
19160-0030
Doc No: ATS-640053500
Revision: D
Application Tooling
Specification Sheet
Wire Size (AWG)
18
16
14
12
10
* UL – 486 C – Closed end connectors and Wire Nuts.
Terminal Eng No. (REF)
NC-1610
NC-1610-BA
NC-1610-L
NC-1610-Y
NC-S1610
Release Date: 09-05-05
Revision Date: 07-08-16
Engineering No. AT 1610
*UL – 486 C
10
15
25
35
40
Wire Size
Wire Combinations
AWG
mm²
10 - 16
(5.00-1.30)
See Chart 1
10 - 16
(5.00-1.30)
See Chart 1
10 - 16
(5.00-1.30)
See Chart 1
10 - 16
(5.00-1.30)
See Chart 1
10 - 16
(5.00-1.30)
See Chart 1
UNCONTROLLED COPY
Order No. 64005-3500
Page 1 of 7
Advertisement
Table of Contents
Related Manuals for molex AT 1610
Summary of Contents for molex AT 1610
- Page 1 The following is a partial list of the product part numbers and their specifications that this tool is designed to run. We will be adding to this list and an up to date copy is available on www.molex.com. Wire Size Terminal No.
- Page 2 AT-1610 Head Crimp Tool OPERATION Refer to the instruction manual for the 19279-0001 (AT200) for mounting this crimp tool head. CAUTION: This crimp tool requires a regulated air supply line with operating pressure of 60 to 70 PSI. Higher pressure may cause damage to the tool. 3/8 “...
- Page 3 CAUTION: Never place fingers in the tool nests. 4. Remove the crimped connector and inspect for proper crimp location and insulation closure. Molex offers a Crimp Inspection Handbook for closed barrel industrial product. See our website or contact your sales engineer.
- Page 4 30 days. Should such a defect occur, we would repair or exchange the tool free of charge. This repair or exchange will not be applicable to alter, misused or damaged tools. CAUTION: Molex crimp specifications are valid only when used with Molex terminals, applicators and tooling. UNCONTROLLED COPY...
- Page 5 AT-1610 Head Crimp Tool PARTS LIST Item Order No Description Quantity 64005-3500 Crimp Tool Head Figure 5 64005-0120 Air Tool Head, Nose Mount 64001-3575 Locator Assembly 64001-3570 Tooling Kit Tooling Kit Only 64001-3501 Conductor Punch 64001-3502 Conductor Anvil #6-32 X 1/4” LONG SHCS Figure 5 UNCONTROLLED COPY...
- Page 6 AT-1610 Head Crimp Tool Parts List (Continued) Item Order No. Description Quantity 64005-0120 Air Tool Head, Nose Mount Figure 6 64000-0077 Repair Kit (Springs, Rods Pivots, Rings, and Washers) #4-40 by 3 /8”Long SHCS M4 by 12LG. Freedrive Pan Head Screw 3/16”...
- Page 7 AT-1610 Head Crimp Tool Air Powered Crimp Tool Head Certificate of Calibration Order No. 64005-3500 Engineering No. AT 1610 Tool Order Number_____________________ Tool Eng. Number______________________ Tool Revision_________________________ Serial Number________________________ Date of Manufacture____________________ Pin Gauge of Conductor Nest/Nests or Slug height if the nest is the “F” Crimp style.
