AT-1200 Air Crimp Tool Head
Air Powered
Crimp Tool Head
Krimptite
FEATURES
Quick-change tool head for the 19279-0001 (AT-200)
Tooling kit is interchangeable with other kits in the 64001 and 64003 Series
A precision user-friendly terminal locator wire stop holds terminals in the proper crimping position
Pneumatic powered crimp tools help reduce fatigue and discomfort from repetitive manual crimping
SCOPE
Products: Krimptite™ Flag Ring and Spade Terminals, 18–22 AWG. This tool head is intended for use in the
19279-0001 (AT-200) either hand held or with optional bench adapter 19078-0307 (ATBA) and foot switch.
Testing
Mechanical
The tensile test, or pull test, is a means of evaluating the mechanical properties of the crimped connections.
The following charts show the UL specifications for various wire sizes. The tensile strength is shown in
pounds and indicates the minimum acceptable force to break or separate the terminal from the conductor.
The following is a partial list of the product part numbers and their specifications that this tool is designed to
run. We will be adding to this list and an up to date copy is available on www.molex.com.
Terminal No.
19041-0001
19041-0003
19041-0005
Doc No. ATS-640073000
Revision: C
Application Tooling
Specification Sheet
Wire Size (AWG)
22
20
18
*UL - 486 A - Terminals (Copper conductors only)
Wire Size: 18 – 22 AWG 0.80 – 0.35mm²
Terminal Eng No. (REF)
B-142-06
B-142-08
B-142-10
Release Date: 12-22-03
Revision Date: 11-10-06
*UL - 486 A
8
13
20
Wire Strip Length
Insulation Diameter Maximum
In.
mm
In.
.281
7.14
N/A
.281
7.14
N/A
.281
7.14
N/A
UNCONTROLLED COPY
Order No. 64007-3000
Engineering No. AT 1200
mm
N/A
N/A
N/A
Page 1 of 6
Advertisement
Table of Contents
Related Manuals for molex 207129 Series
Summary of Contents for molex 207129 Series
- Page 1 The following is a partial list of the product part numbers and their specifications that this tool is designed to run. We will be adding to this list and an up to date copy is available on www.molex.com. Wire Size: 18 – 22 AWG 0.80 – 0.35mm²...
- Page 2 AT-1200 Air Crimp Tool Head Operation Refer to the instruction manual for the 19279-0001 (AT-200) for mounting this crimp tool head. Crimping Terminals 1. Slip the ring or spade of the flag terminal under the locator tab and center the terminal barrel into the conductor punch of the lower jaw. Make sure the LOCATOR open side of the barrel is facing down.
- Page 3 30 days. Should such a defect occur, we would repair or exchange the tool free of charge. This repair or exchange will not be applicable to altered, misused or damaged tools. CAUTION: Molex crimp specifications are valid only when used with Molex terminals, applicators and tooling. UNCONTROLLED COPY Doc No.
- Page 4 AT-1200 Air Crimp Tool Head PARTS LIST Item Order No Description Quantity 64007-3000 Crimp Tool Head Figure 5 64005-0000 Basic Air Tool Head 64003-0875 Locator Assembly 64003-3070 Tooling Kit Tooling Kit Only 64003-3002 Conductor Anvil 64003-3001 Conductor Punch #4 40 X 1/8 LONG BHCS Figure 5 UNCONTROLLED COPY...
- Page 5 AT-1200 Air Crimp Tool Head Parts List (Continued) Item Order No. Description Quantity 64005-0000 Basic Air Tool Head Figure 6 64005-0103 Nose Guard 64000-0077 Repair Kit (Springs, Rods Pivots, Rings, and Washers) M4 by 12 Long Freedrive Pan Head Screw 3/16”...
- Page 6 Technician _____________________ Date of Calibration ________________ Calibration should be done every 5,000 cycles or 3 months. Tools should be lubricated during this operation. Visit our Web site at http://www.molex.com UNCONTROLLED COPY Doc No. ATS-640073000 Release Date: 12-22-03 Page 6 of 6...
