RELIEVING WATER PRESSURE WITH THE
BYPASS VALVE(S)
CAUTION: Always relieve water pressure in the
EcoWater Systems filter, as described below, before
removing parts from the valve or media tank.
DE-PRESSURIZE
1. Put bypass valve(s) into Bypass position.
2. Place filter valve in Fill position by performing Steps
1 & 5 of Manual Advance Recharge procedure on
Page 30.
PRESSURIZE
1. Put bypass valve(s) into Service position.
2. Return filter valve to Service position by performing
Steps 6-11 of Manual Advance Recharge procedure
on Page 30.
ALTERNATE METHODS:
3-VALVE BYPASS
(See Figure 93)
DE-PRESSURIZE
1. Close the INLET valve.
2. Open HOT and COLD conditioned water house
faucets.
3. Close the OUTLET valve and open the BYPASS
valve.
4. Close all house faucets.
PRESSURIZE
1. Open HOT and COLD house faucets.
2. Close the BYPASS valve and open the OUTLET
valve.
3. Slowly, open the INLET valve.
4. Close all house faucets.
ECOWATER SYSTEMS BYPASS VALVE
(See Figure 94)
DE-PRESSURIZE
1. Close the house main water supply valve.
2. Open HOT and COLD conditioned water house
faucets.
3. Push the bypass valve handle to Bypass position.
4. Optional: For unfiltered water bypass to house
faucets, reopen the main water supply valve.
PRESSURIZE
1. Open main water supply valve if it is closed.
2. Open HOT and COLD house faucets.
3. Pull the bypass valve handle to Service position.
4. Close all house faucets.
OUTLET
VALVE
For Service
Close Bypass Valve.
Open Inlet & Outlet
Valves.
EcoWater Systems Bypass Valve
27
Service Information
3-Valve Bypass
BYPASS
VALVE
From
Filter
To
Filter
For Bypass
Open Bypass Valve.
Close Inlet & Outlet
Valves.
Pull out for Service
(Filtered water)
Push in for
Bypass
INLET
VALVE
FIG. 93
FIG. 94
