MAIN MENU
Main menu
Recharge
Basic settings
User preferences
During normal operation (status screens rolling), press
the filter's SELECT ( ) button to display the Main menu
(See Figure 33). This menu and its subsidiary screens
are used to control these operations:
Recharge (See Page 17)
=
Basic settings
=
Current time (See next column)
=
Max. days between recharges (See Page 18)
=
Recharge time (See Page 19)
=
Rolling screens (See Page 19)
=
User preferences
=
Language (See Page 20)
=
Time format (See Page 20)
=
Volume units (See Page 20)
=
System information
=
Model information (See Page 21)
=
Wireless information (See Page 21)
=
Daily avg. water used (See Page 21)
=
Water used today (See Page 21)
=
Total water used (See Page 21)
=
Current water flow (See Page 21)
=
Days powered up (See Page 21)
=
Last recharge (See Page 21)
=
Total recharges (See Page 21)
=
Advanced settings
=
Cycle times
=
Fill time (See Page 23)
=
Draw time (See Page 23)
=
Backwash time (See Page 22)
=
Second backwash (On/Off) (See Page 22)
=
Second backwash time (See Page 22)
=
Fast rinse time (See Page 22)
=
Special features
=
Auxiliary control (See Page 24)
=
Chemical feed volume** (See Page 24)
=
Chemical feed timer** (See Page 24)
=
Service reminder (See Page 23)
=
Troubleshooting
=
Diagnostics (See Page 25)
=
Setup changes (See Page 25)
=
Wireless setup (See Pages 10-13)
=
**Only displayed if Auxiliary control is set to Chemical
feed.
SETTING THE CURRENT TIME
When the filter's electronic control is first powered up, a
"wizard" screen prompts you to set the current time
(See Pages 10-12). To change the time at a later date,
such as after a long power loss:
FIG. 33 1. From any of the rolling status screens, press the
SELECT ( ) button to display the Main menu.
2. Press the DOWN (6) button to scroll through the
menu options until Basic settings is highlighted
(See Figure 34).
3. Press the SELECT ( ) button to display the Basic
settings menu (See Figure 35).
4. Make sure Current time is highlighted.
5. Press the SELECT ( ) button to display the Current
time screen (See Figure 36).
6. Press the UP (5) or DOWN (6) buttons to change
the time. Hold the button down to rapidly advance.
Be sure that AM or PM is correct (unless filter is set
for a 24-hour clock).
7. Press the SELECT ( ) button. The display will go
back to the Basic settings menu (Figure 35).
8. Press the LEFT (3) button twice to return to the
rolling status screens.
NOTE: On Wi-Fi connected systems, the current time
15
Filter Operation
Main menu
Recharge
Basic settings
User preferences
Basic settings
Current time
Max. days between rech...
Recharge time
Current time
12:34 PM
will be updated and maintained automatically
via Wi-Fi.
FIG. 34
FIG. 35
FIG. 36
