Coding transmitters

fi g 14
Press and hold
Door Code button
Coding hole
fi g 15
Small needle
9. Setting transmitters codes
Make sure to insert the battery into the transmitters.
The memory in the openers receiver can store up to
eight remote control transmitters.
9.1 Storing the transmitters code
1. Press and hold the Door Code button (Fig. 14).
2. Press the button (one of four) on the transmitter
you would like to use to control the door for
two seconds, pause for two seconds. Press the
same button again on the transmitter for two
seconds.
3. Release the Door Code button.
4. Press the transmitter button to test if it operates
the door.
10. Storing transmitter(s) from
a remote location
Using this method you don't need to have access
to the control panel on the Door Opener. However,
you do need a transmitter that is pre coded to the
controller's receiver.
GDO-8v1 EasyRoller® II
16
IMPORTANT NOTE: The door must be activated
when the step below is performed. The moving door
confi rms that the correct button was pressed and
the transmitter was in range of the opener.
1. Take any pre-coded transmitter. Press the button for
2. Using a small needle press the button through the
3. Within 10 seconds take the additional transmitter you
4. Press the button (one of four) on the new transmitter
Select one of the four
buttons you wish to use
to control the door
5. Wait for 10 seconds and then test the new transmitter
11. Deleting programmed codes
11.1 deleting a stored transmitter code
1. Select the transmitter you want to delete.
2. Press and hold the Door Code button (Fig. 14).
3. Press the transmitter button you would like to delete
4. Release the Door Code button. The code should now
11.2 Deleting all stored transmitter codes
1. Turn the power off to the opener.
2. Press and hold the Door Code button (Fig. 14).
3. Turn the power on again while holding the Door Code

12. Locking the control panel

To lock or disable the control panel a transmitter button
must be coded specifi cally for this purpose.
1. Press and hold Door Code and Plus (+) button
2. Release both buttons.
3. The control panel should now be locked. Press the
To unlock the control panel repeat the above steps.
Owner Installation Instructions
the function you require until the door is activated
and release.
Coding Hole for two seconds (Fig. 15).
wish to code.
you would like to use to control the door for two
seconds, pause for two seconds. Press the same
button again on the transmitter for two seconds, the
button should now be stored.
to see if it operates the door.
for two seconds. Pause for two seconds. Press the
transmitter button again for two seconds.
be deleted. Confi rm this by pressing the transmitter
button, the door should not respond.
button. The Open Limit, Close Limit and Door Status
LED's will illuminate for about fi ve seconds. These
LED's will turn Off and the Coding LED will illuminate.
Release the Door Code button. All the stored codes
should now be deleted. Confi rm this by trying
to operate the door by pressing the transmitters
previously used to control the door, the door should
not respond.
together until you hear a beep (approx. four (4)
seconds).
Operate button to confi rm the door does not move.
