4 • Cresnet 4-Channel Digital Volume Control: C2N-VEQ4
2. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product
Catalog for a complete list of 2-Series control systems.
3. Filenames for CNX and ST-CP update files have a UPZ extension. Files on the website may be .zip or
self-extracting .exe files containing the .cuz or .upz file. All can be obtained from the Downloads
section of the Crestron website. To avoid program problems, make sure you are using the update file
with the correct suffix letter (e.g., S, V, W, X).
NOTE: Crestron software and any files on the website are for Authorized Crestron
dealers and Crestron Authorized Independent Programmers (CAIP) only. New users
may be required to register to obtain access to certain areas of the site (including the
FTP site).

Physical Description

The C2N-VEQ4, shown below, is housed in a black enclosure with labeling on the
front and rear panels. Six LEDs on the front of the unit indicate the unit's status. All
connections are made on the back of the unit. There are four rubber feet on the base
of the unit for stability and to prevent slippage
C2N-VEQ4 Physical Views
