Crestron C2N-MMS
Operations Guide – DOC. 6374
Specifications for the C2N-MMS (continued)
SPECIFICATION
Supported Video Signal
Formats
Bandwidth
Firmware
Control System Update
1,2
Files
2-Series Control System
MP2/MP2E
Operating Temperature
and Humidity
Dimensions and Weight
1. The latest software versions can be obtained from the Crestron website. Refer to the NOTE following
these footnotes.
2. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product
Catalog for a complete list of 2-Series control systems.
NOTE: Crestron software and any files on the website are for Authorized Crestron
dealers and Crestron Authorized Independent Programmers (CAIP) only. New users
may be required to register to obtain access to certain areas of the site (including the
FTP site).

Physical Description

The front panel of the C2N-MMS contains a green (PWR) and yellow (NET) LED
that illuminate when power is on and during network communications respectively.
The rear panel of the C2N-MMS contains ten BNC connectors that compose the
three chrominance/luminance (Y/C) video inputs and two Y/C video outputs. The
C2N-MMS also contains six HD15 connectors that compose the four RGB inputs
and two RGB outputs. DIP switches located inside the device are used to configure
the RGB inputs. For more information on the DIP switches, refer to "Configuring the
RGB Input Ports" on page 11. Two four-position terminal block connectors provide
connectivity to the Cresnet network. A pushbutton with an indicating red LED
marked "SETUP" is for Touch-Settable ID operation.
NOTE: DIP switches for selecting sync input impedance and the DDC feature are
only available on C2N-MMS devices with the part number 6003312 on the
manufacturing label located on the bottom of the unit. Units labeled with part
number 6001581 do not have this feature.
The C2N-MMS can be placed in a rack (with included mounting ears) or on a table
with the supplied rubber feet. Refer to "Rack Mounting" on page 14 for more
information.
Professional Multimedia Switch
DETAILS
National Television System Committee (NTSC) &
Phase Alternating Line (PAL)
RGB: 400 MHz (-3 dB) at unity gain
Video: 100 MHz (-3 dB) at unity gain
C2N-MMS.v2.14.upg or later
Version C2-V3015.CUZ or later
Version MP2-V3016.CUZ or later
41º to 104º F (5º to 40º C),
10 to 90% Relative Humidity (non-condensing)
Height: 1.70 in (4.32 cm)
Width: 17.03 in (43.26 cm) without mounting ears
Depth: 7.15 in (18.16 cm)
Weight: 3.4 lbs (1.5 kg)
Professional Multimedia Switch: C2N-MMS • 5
