Specifications - Crestron C2N-MMS Operation Manual

Professional Multimedia Switch
4 • Professional Multimedia Switch: C2N-MMS

Specifications

The following table provides a summary of specifications for the C2N-MMS.
Specifications for the C2N-MMS
SPECIFICATION
®
Cresnet Power Usage
Default NET ID
RGB Input Channels
Type
Impedance
Input Levels
Sync Input Level
Sync Impedance
Video Input Channels
Type
Impedance
Input Levels
RGB Output Channels
Type
Output Level
Impedance
Sync Output Level
Sync Impedance
Sync Max Rise/Fall
Time
Sync Latency
Sync Polarity
Video Output Channels
Type
Impedance
Output Level
RGB Input/Output Format
Maximum RGB Output
Cable Length
(continued on following page)
Crestron C2N-MMS
DETAILS
6 Watts (0.25 Amp @ 24 VDC)
11
(4) D-15 with Auto-Detect on H sync
75 ohms
0.3V to 1.5 V with no offset at unity gain
pp pp
Max DC offset with min input: ±1.0 V
Max DC offset with max input: ±0.5 V
offset tolerant to ±2.5 VDC offset
2.0 V to 5 V
pp pp
max.
1k ohms, 500 ohms, 75 ohms
(Selectable via DIP switches)
(3) BNC S-Video or Composite with
Auto-Detect on the Y input
75
0.3V to 1.5V with no offset at unity gain
pp pp
Max DC offset with min input: ±1.0V
Max DC offset with max input: ±0.5V
(2) D-15 with Frequency/Level Compensation and
3 dB Signal Boost
0.7 V to 0.75 V terminated with 0.7 V
pp pp
75 ohms
4.0 V to 5.0 V
pp pp
33 ohms
3.5 ns
< 30 ns
Follows input
(2) BNC S-Video or Composite
75 ohms
1.0 V to 1.1 V terminated with 1.0 V
pp pp
(composite)
RGBHV
Min Resolution: 460 x 400
Max Resolution: 2048 x 1536
Tested to 100 feet. Cable length in excess of 100
feet may be subject to signal degradation.
Operations Guide – DOC. 6374
input
pp
input
pp
