- Page 1 Crestron CNX-ASBK Audio Switcher Bussing Kit Operations & Installation Guide...
-
Page 2: Table Of Contents
Crestron CNX-ASBK Contents Audio Switcher Bussing Kit: CNX-ASBK Description Functional Description Physical Description Identity Codes of the CNX-PAD8s Installing CNX-ASBKs into CNX-PAD8s Industry Compliance Programming Daisy-Chained CNX-PAD8s Problem Solving Troubleshooting Further Inquiries Future Updates Return and Warranty Policies Merchandise Returns / Repair Service CRESTRON Limited Warranty Operations &... -
Page 3: Audio Switcher Bussing Kit: Cnx-Asbk
(not supplied). A maximum of four CNX-PAD8s may be daisy-chained together to provide up to 32 room outputs. The CNX-ASBK provides for the additional outputs by bussing up to eight inputs while preventing extreme impedance loading. One kit is needed for each CNX-PAD8 that is to be daisy-chained. -
Page 4: Identity Codes Of The Cnx-Pad8S
2. Attach one of the CNX-PAD8s that needs to have its Net ID changed to the control system. 3. Select Tools | Viewport to open “Crestron Viewport” dialog box. 4. Select Functions | Set Network ID. The software checks the baud rate and then opens the “Set Network ID”... -
Page 5: Installing Cnx-Asbks Into Cnx-Pad8S
Crestron CNX-ASBK Installing CNX-ASBKs into CNX-PAD8s One CNX-ASBK is required for each CNX-PAD8 that is to be daisy-chained. The only tools required are a Phillips tip screwdriver and a grounding strap. Follow the assembly procedure and illustrations that begin after this paragraph. - Page 6 NOTE: The remaining steps of this procedure describe the installation of one CNX-ASBK into one CNX-PAD8. The steps apply to all of the CNX-PAD8s to be daisy-chained and may be performed in an “assembly line” fashion on all of the CNX-PAD8s at the same time.
- Page 7 CNX-PAD8. Carefully align and insert the other connector onto the connector on CNX-PAD8 processor PCB. 13. Curl the cable directly above and insert the other connector onto the pins of the PCB as shown. Audio Switcher Bussing Kit: CNX-ASBK • 5 10 COVER PLATE SCREWS...
- Page 8 If the cable does not fit correctly, switch the cable ends from one CNX-PAD8 to another. DO NOT force the connector onto pins. Install the Bussing Cables 6 • Audio Switcher Bussing Kit: CNX-ASBK 14. Repeat the previous two steps for all of the remaining PCB to PCB cables.
-
Page 9: Industry Compliance
23. Using network device cables (not supplied), daisy-chain each CNX-PAD8 to each other or the control system. 24. At the rear of the CNX-PAD8s, connect the electrical power (4-pin Cresnet power connectors and/or the external power packs). Audio Switcher Bussing Kit: CNX-ASBK • 7... -
Page 10: Problem Solving
For assistance in your local time zone, refer to the Crestron website (www.crestron.com) for a listing of Crestron worldwide offices. You can also log onto the online section of the Crestron website (www.crestron.com) to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
Page 11: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 12 Crestron Electronics, Inc. Operations & Installation Guide – DOC. 8143 15 Volvo Drive Rockleigh, NJ 07647 07.99 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
