Introduction

Features and Functions

The CLW-SW (-SW) is a stand-alone wall box switch
that can also act as a Cresnet
®
Crestron control processor. The -SW includes two
isolated, non-polarized Cresnet wires (plus a ground wire)
for connecting to a Cresnet system over a twisted pair
wire with shield.
The CLW-SW features a three-position mode selection
switch. Refer to "Operating Buttons and Switches " on
page 5 for more information. In the absence of Cresnet
communications, the switch can still be used to control a
load.
The CLW-SWS (-SWS) is similar to the -SW with the
added capability of working with a slave unit
(CLW-SLVS) in a multi-switch / single circuit
application.
The CLW-SLVS (-SLVS) is a slave unit that when used
in conjunction with the -SWS acts as an additional switch
control point in a multi-switch / single circuit application.
It does not connect to a Cresnet system and cannot be
used without a -SWS. The -SLVS does not have a mode
selection switch and is not programmable. It emulates the
operation of the -SWS to which it is connected.
The -SW, -SWS, and -SLVS are available in white,
almond, and black. White units are designated by part
numbers ending in "W". Almond units are designated by
part numbers ending in "A". Black units are designated by
part numbers ending in "B". These switches can be
covered with a decorative faceplate (not supplied).

Specifications

Following are specifications for the -SW, -SWS, and
-SLVS.
CLW-SW, CLW-SWS, & CLS-SLVS Specifications
SPECIFICATION
Power Requirements
Default Net ID
Switch Type
Load Type
2-Series Control System
1,2
Update File
(continued on next column)
Crestron Electronics, Inc.
15 Volvo Drive Rockleigh, NJ 07647
Tel: 888.CRESTRON
Fax: 201.767.7576
www.crestron.com
®
device that reports to a
DETAILS
Line Power, 120 VAC, 60 Hz
SW: 6F
SWS: 70
Single-Pole, Single-Throw
Incandescent, Tungsten Halogen,
Fluorescent / High Intensity
Discharge (HID), Electronic Low
Voltage, Magnetic Low Voltage, Neon
/ Cold Cathode, General Purpose Fan
Version 3.093 or later
CLW-SW, SWS, & SLVS(W/A/B)
CLW-SW, CLW-SWS, & CLS-SLVS Specifications
(continued)
SPECIFICATION
3
Load Ratings
Incandescent / Tungsten
Halogen
Magnetic Low Voltage
Neon / Cold Cathode
Electronic Low Voltage
Fluorescent /
High Intensity Discharge
(HID)
General Purpose Fan
Minimum Load
Operating Temperature
and Humidity
Dimensions and Weight
1. The latest software versions can be obtained from the Crestron
website. Refer to the NOTE following these footnotes.
2. Crestron 2-Series control systems include the AV2 and PRO2.
Consult the latest Crestron Product Catalog for a complete list of
2-Series control systems.
3. Refer to Derating Charts for Multigang Installations on page 3.
4. VA ratings are for input power to the transformer. If you do not
know the input power requirement of the transformer, use the
bulb's wattage rating to determine proper rating.
NOTE: Crestron software and any files on the website
are for Authorized Crestron dealers and Crestron
Authorized Independent Programmers (CAIP) only. New
users may be required to register to obtain access to
certain areas of the site (including the FTP site).
DETAILS
-SW: 1000W
-SWS: 1000W
-SLVS: N/A
4
-SW: 1000VA/750W
-SWS: 1000VA/750W
-SLVS: N/A
4
-SW: 1000VA/750W
-SWS: 1000VA/750W
-SLVS: N/A
-SW: 1000W
-SWS: 1000W
-SLVS: N/A
-SW: 8A
-SWS: 8A
-SLVS: N/A
-SW: 3.0A
-SWS: 3.0A
-SLVS: N/A
40W / 0.5A
32°F to 104°F (0°C to 40°C )
10 to 90% Relative Humidity
(Non-Condensing)
-SW and -SWS:
Height: 4.13 in (10.48 cm)
Width: 2.38 in (6.03 cm)
Depth: 1.91 in (4.85 cm)
Weight: 4.4 oz (0.61 kg)
-SLVS:
Height: 4.13 in (10.48 cm)
Width: 1.75 in (4.45 cm)
Depth: 1.91 in (4.85 cm)
Weight: 3.6 oz (0.50 kg)
Installation Guide – DOC. 6134B
Specifications subject to
change without notice.
(2008088)
06.05
