CYW943907AEVAL1F Evaluation Kit User Guide, Doc. No. 002-18703 Rev. *B
CYW43907 Pin Name Net Name in Schematic
RMII_G_TXD1 MII_TXD1
RMII_G_TXD2 MII_TXD2
RMII_G_TXD3 MII_TXD3
RMII_G_RXD0 MII_RXD0
RMII_G_RXD1 MII_RXD1
RMII_G_RXD2 MII_RXD2
RMII_G_RXD3 MII_RXD3
RMII_MDIO MII_MDIO
RMII_MDC MII_MDC
RMII_G_TXEN MII_TXEN
RMII_G_RXDV MII_RXDV_CRS_DV
PWM_2 PWM_2
BCM5241 Pin Name
TXD1
TXD2
TXD3
RXD0/PHYAD0
RXD1/ANEN_L
RXD2/F100
RXD3/ISOLATE
MDIO
MDC
TXEN
RXDV
RESET_L
Hardware
