- Page 1 Please note that Cypress is an Infineon Technologies Company. The document following this cover page is marked as “Cypress” document as this is the company that originally developed the product. Please note that Infineon will continue to offer the product to new and existing customers as part of the Infineon product portfolio.
- Page 2 CY6611 EZ-USB HX3PD Evaluation Kit Guide Document Number: 002-26068 Rev *A Cypress Semiconductor An Infineon Technologies Company 198 Champion Court San Jose, CA 95134-1709 www.cypress.com www.infineon.com...
- Page 3 (“Unintended Uses”). A critical component is any component of a device or system whose failure to perform can be reasonably expected to cause the failure of the device or system, or to affect its safety or effectiveness. Cypress is not liable, in whole or in part, and you shall and hereby do release Cypress from any claim, damage, or other liability arising from or related to all Unintended Uses of Cypress products.
-
Page 4: Table Of Contents
Demonstrating USB PD Charging on US and DS1 Ports ..................25 4.5.1 Troubleshooting ............................26 Programming the HX3PD Controller .......................... 27 EZ-USB HX3PD Configuration Utility Overview ....................27 Programming the HX3PD Firmware ........................27 CY6611 EZ-USB HX3PD Evaluation Kit Guide, Document Number: 002-26068 Rev *A... - Page 5 Contents Updating the HX3PD Configuration and Generating a Composite Image ............29 Appendix A: Terminology ..............................30 Revision History ................................... 31 Document Revision History ............................31 CY6611 EZ-USB HX3PD Evaluation Kit Guide, Document Number: 002-26068 Rev *A...
-
Page 6: Safety Information
Handling Boards CY6611 EZ-USB HX3PD EVK boards are sensitive to ESD. Hold the board only by its edges. After removing the board from its box, place it on a grounded, static-free surface. Use a conductive foam pad if available. Do not slide the board over any surface. - Page 7 Do not apply reverse voltage on the power domain test points. Identifying Kit Revision and Serial Number The CY6611 kit revision and serial number are printed on a sticker and pasted at the bottom side of the CY6611 kit box. See the figure below for more details.
-
Page 8: Introduction
Type-C and PD standards. CYUSB4347-BZXC is a USB-IF certified USB 3.1 Gen 2 (10 Gbps) hub silicon (TID # 5030000008). The CY6611 EVK is a 7-port evaluation kit designed to demonstrate the USB 3.1 Gen 2 hub, PD 3.0 and Battery Charging (BC 1.2) functionalities of the HX3PD controller. -
Page 9: Getting Started
HX3PD controller. The online resources provided in Cypress’ official website also help you to quickly and effectively integrate the device into your design. The following is the list of online references for HX3PD and CY6611 EVK: ... -
Page 10: Abbreviations
Personal Computer Power Delivery Power Data Object Product ID Serial Clock Serial Data Standard Downstream Port Serial Peripheral Interface SuperSpeed Upstream Facing Port Upstream Universal Serial Bus Vendor ID CY6611 EZ-USB HX3PD Evaluation Kit Guide, Document Number: 002-26068 Rev *A... -
Page 11: Installation
EZ-PD Configuration Utility: This utility is launched by the EZ-USB HX3PD Configuration Utility to configure the DMC and PD Controller firmware. The CY6611 EVK installation is a three-step process which is described in the following sections. Make sure that the installation is done only in the same order as specified. -
Page 12: Installing The Ez-Usb Hx3Pd Configuration Utility
Click Next when the screen shown in Figure 2-3 appears and proceed with the installation process. Figure 2-3. CY6611 EZ-USB HX3PD EVK Installer Screen CY6611 EZ-USB HX3PD Evaluation Kit Guide, Document Number: 002-26068 Rev *A... -
Page 13: Cypress Update Manager Check
CY6611 EVK. Scroll through the list to locate CY6611 EVK. Note 2: You can launch the Cypress Update Manager at any time from Start > All Programs > Cypress > Cypress Update Manager. Note 3: After the installation is complete, the contents are available at this location: <Install Directory>\CY6611 EZ-USB HX3PD EVK\1.0\. -
Page 14: Cy6611 System Design
3 CY6611 System Design This chapter describes the features supported by the CY6611 EVK and the hardware design details of the EVK. 3.1 CY6611 EVK Overview CY6611 EVK enables evaluation of the following features of the EZ-USB HX3PD controller: ... -
Page 15: Cy6611 Hardware Design
3.2.1 CY6611 Hardware Design Overview Figure 3-1 illustrates the CY6611 hardware design. CY6611 hardware is designed to evaluate the USB Gen 2 and USB PD capabilities of HX3PD controller on all applicable ports. Figure 3-1. CY6611 EVK Hardware Block Diagram The board is powered through one of the following two DC input interfaces: DC Power Jack (J12), DC Terminal (J11). -
Page 16: Cy6611 Jumpers, Leds And Headers
CY6611 System Design The hardware design files of CY6611 EVK (Schematics, BoM, and layout files) are available as part of the kit installation at <Install_Directory>\CY6611 EZ-USB HX3PD EVK\1.0\Hardware. Note: On Windows 32-bit platforms, the default <Install Directory> is C:\Program Files\Cypress, and on Windows 64-bit platforms, it is C:\Program Files (x86)\Cypress. - Page 17 Pin # 1 of J3 header CY6611 EVK board has two 26-pin headers (J3 and J4) which provide access to the key pins of the HX3PD controller. The signals terminated on these headers are marked as part of CY6611 EVK board’s top side silkscreen as shown in Figure 3-3.
- Page 18 GPIO for EEPROM Write DMC_P24 PD_HUB_INT Reserved Protect enable VCONN_MON_P1 GPIO of PD Controller I2C_SCL_EC I2C SCL for EC VCONN_MON_P0 GPIO of PD Controller I2C_SDA_EC I2C SDA for EC CY6611 EZ-USB HX3PD Evaluation Kit Guide, Document Number: 002-26068 Rev *A...
-
Page 19: Measuring Power Consumed By Hx3Pd Controller
Remove the jumpers installed at jumper headers J6 (1.2-V supply) and J10 (3.3-V supply). Set both the digital multimeters in Ampere mode and attach them to headers J6 and J10. Supply power to the CY6611 EVK board and operate the features of the kit as required. See the Kit Operation chapter for more details. -
Page 20: Kit Operation
Figure 4-1. Connect the power adapter provided with the kit to the DC Power Jack (J12) of the CY6611 EVK board. Plug the other end of the power adapter into an AC power socket. Power LEDs (LED3 - LED5) glow green to indicate that the kit is powered. Also, the PD CTRLR LED and DMC LED blink green to indicate that the firmware is running and the kit is ready for operation. - Page 21 Note: The maximum power consumed by all ports should not exceed 55 W when used with the power adapter provided with the kit. If the total power requirement for the devices to be connected to the ports of CY6611 EVK exceeds 55 W, use a higher capacity power source to power the kit.
-
Page 22: Troubleshooting
4.3 Connecting EVK to Laptop Connect the Type-C cable provided with the kit to the CY6611 EVK board’s US port. Connect the other end of the Type-C cable to the Type-C port on a laptop supporting USB 3.1 Gen 2 (10 Gbps) and USB PD. - Page 23 Expand Universal Serial Bus controllers to see the list of USB devices attached to the laptop. The evaluation kit is listed as Generic SuperSpeed USB Hub and Generic USB Hub. Figure 4-4. Enumeration of HX3PD on the Laptop CY6611 EZ-USB HX3PD Evaluation Kit Guide, Document Number: 002-26068 Rev *A...
-
Page 24: Demonstrating Usb 3.1 Gen 2 (10 Gbps) Data Transfer
4.4 Demonstrating USB 3.1 Gen 2 (10 Gbps) Data Transfer This section demonstrates the USB 3.1 Gen 2 (10 Gbps) data transfer capability of the HX3PD controller using the CY6611 EVK. This section also demonstrates the procedure for USB 2.0 transfer. -
Page 25: Troubleshooting
PC and port while data transfer is in progress detach events on USB check causes data transfers happening on other DS ports to stop CY6611 EZ-USB HX3PD Evaluation Kit Guide, Document Number: 002-26068 Rev *A... -
Page 26: Demonstrating Usb Pd Charging On Us And Ds1 Ports
4-9. Note: The CY6611 firmware is configured to support a maximum of 20 V, 2.3 A power on the US port and 5 V, 1 A power on the DS1 port. The CY6611 firmware can be configured to support a maximum power of 20 V, 3 A on both US and DS1 ports simultaneously. -
Page 27: Troubleshooting
CY6611 EVK’s DS1 port is not charging The device’s implementation may require The CY6611 firmware is configured to support 5 V, 1 A higher voltage PD contract to be PD contract on DS1 by default. The CY6611 firmware established with CY6611 EVK to enable... -
Page 28: Programming The Hx3Pd Controller
Detach the SSD and other drives/devices from the DS ports. Connect the power adapter provided with the kit to the DC Power Jack (J12) of the CY6611 EVK board. Plug the other end of the power adapter into an AC power socket. - Page 29 Go to the Update Firmware tab and specify the path to the HX3PD firmware file in the Composite image field as shown in Figure 5-3. Retain the default values for the other fields. The HX3PD firmware is available at <Install_Directory>\CY6611 EZ- USB HX3PD EVK\1.0\Firmware\HX3PD_Composite_FW\CYUSB4347-BZXC_FW.bin. Click Update to initiate programming of the HX3PD firmware.
-
Page 30: Updating The Hx3Pd Configuration And Generating A Composite Image
5.3 Updating the HX3PD Configuration and Generating a Composite Image The HX3PD firmware can be configured based on the CY6611 EVK usage requirements. For example, the default USB PD PDO of 5-V, 1-A supported on DS1 port can be modified to support 20-V, 2.25-A. See the EZ-USB HX3PD Configuration Utility User Guide to understand the procedure. -
Page 31: Appendix A: Terminology
Fast Role Swap (FRS): Ability of a Dual Role Port (DRP) to switch power roles between sink and source. The FRS was introduced with latest power delivery specification (USB PD v3.0). Figure A-1: USB Type-C Plug and Receptacle CY6611 EZ-USB HX3PD Evaluation Kit Guide, Document Number: 002-26068 Rev *A... -
Page 32: Revision History
Cypress Update Manager Check Updated CY6611 System Design. Added Troubleshooting points in Table 4-1 and Table 4-2. Added note in Demonstrating USB PD Charging on US and DS1 Ports. CY6611 EZ-USB HX3PD Evaluation Kit Guide, Document Number: 002-26068 Rev *A...
