ACP 100 • Setup Guide (Continued)
Step 6: Configure the System
NOTE: For complete information on creating configuration files and operating DSP Configurator, see the host device user
guide and the DSP Configurator Help file.
Create a new host device configuration file in DSP Configurator and create all groups, presets, and macros to be controlled
1.
by the ACP device.
Select Tools>Configure ACPs in DSP Configurator and configure the ACP button actions and panel IDs .
2.
Connect to the host device in Live mode with a TCP/IP connection and push the configuration file to the device.
3.
Step 7: Test and Troubleshoot
Verify the ACP bus ID DIP switches are set to the desired address on each unit and that there are no bus ID address conflicts
1.
in the system.
The ACP 100 may have a single monochrome LED (green) or three separate LEDs (green, amber, or red). The LED (or LEDs)
are a diagnostic tool showing the device status:

Device Status

No power, ACP cable broken.
Device is receiving power and communicating correctly
with the DMP Plus.
Device is receiving power but cannot communicate with
the DMP Plus
Device is receiving power and communicating with the
DMP Plus but there is an address conflict.
Verify cables to and from the ACP devices are wired the same at each end.
2.
Test the system:
3.
Press the ACP device buttons and ensure the buttons light as expected and that the appropriate control actions are
a.
triggered. Commands can be verified using DSP Configurator. DataViewer can also be used for command verification if
responses are configured.
Ensure the audio levels respond correctly to the volume and mute buttons.
b.
Make adjustments to wiring, bus ID addresses, and system configuration as needed. Remember that the rear panel ports
4.
and DIP switches are not accessible after the ACP is mounted. If needed, push a revised configuration to the ACP device
through the host device using DSP Configurator.
If you have questions during installation and setup, call the Extron S3 Sales and Technical Support Hotline or the Extron S3
Control Systems Support Hotline (1.800.633.9877).
6
Single LED (green) Three LEDs
Off Off
Lights solidly Green
Slow blink Amber
Fast blink Red
