PARTS REFERENCE

5.44 LEFT RAMP ASSEMBLY

500-2561-01
6
2
ID Part Number Description
1 515-2410-00 RAMP, GODZILLA, LEFT
2 237-5880-00 SCREW, #6 X 3/8 PPH T-25
3 515-0215-00 LONG RANGE OPTO EMITTER ASSEMBLY
4 515-0215-01 LONG RANGE OPTO RECEIVER ASSEMBLY 1
5 511-5963-01 LEFT BUILDING ASM, PRO
54
3
1
Qty
1
4
1
1
GODZILLA PRO MANUAL 500-55T5-01

5.45 RIGHT RAMP ASSEMBLY

500-2562-00
3
4
ID Part Number Description
1 510-7837-00 RIVETED RAMP ASM, GODZILLA, RIGHT
2 515-0215-01 LONG RANGE OPTO RECEIVER ASSEMBLY 1
3 515-0215-00 LONG RANGE OPTO EMITTER ASSEMBLY
4 237-5997-00 SCREW, 4-40 X 3/8 PPH MS BLACK
ITEM PART
NO. NUMBER
1 510-7837-00 RIVETED RAMP ASM, SPECTRE, RIGHT
2 515-0215-01
3 515-0215-00 LONG RANGE OPTO EMITTER ASSEMBLY
4 237-5997-00 SCREW, 4-40 X 3/8 PPH MS BLACK
4
4X
2
1
DESCRIPTION
LONG RANGE OPTO RECEIVER
ASSEMBLY
Qty
1
1
4
QTY.
1
1
1
4
