4.6 LOWER LEFT LED BOARD 8C

520-8532-00
ID Type Pin
CN1 .100" 9-Pin Header 1
2
3
4
5
6
7
8
9
CN2 .100" 7-Pin Header 1
2
3
4
5
6
7
CN3 .100" 5-Pin Header 1
2
3
4
5
CN4 .100" 6-Pin Header 1
2
3
4
5
6
Description Wire Color
+5 VDC RED
+5 VDC RED
+5 VDC RED
LED 2 YEL-BRN
LED 3 YEL-RED
LED 4 YEL-ORG
LED 5 YEL-GRN
LED 6 ORG-BRN
GND -
Ground BLK
MISO Output Data VIO-BLK
MOSI Input Data VIO-BRN
SCK Serial Clock VIO-RED
RCK Register Clock VIO-ORG
NC -
+5 VDC IN RED
+5 VDC RED
+5 VDC RED
LED 10 ORG-VIO
LED 11 ORG-WHT
LED 12 -
Ground -
MISO Output Data -
MOSI Input Data -
SCK Serial Clock -
RCK Register Clock -
V+ -
GODZILLA PRO MANUAL 500-55T5-01
ELECTRONIC PINOUTS AND SCHEMATICS

4.7 1-RGB 2-W LED BOARD 9A1

520-8538-00
ID Type Pin
CN1 .100" 6-Pin Header 1
2
3
4
5
6

4.8 4-W LED BOARD 9A2

520-8539-00
ID Type Pin
CN1 .100" 5-Pin Header 1
2
3
4
5
Description Wire Color
+5 VDC RED
LED 1-R RED-BRN
LED 1-G GRN-BRN
LED 1-B BLU-BRN
LED 2 ORG-BLU
LED 3 ORG-VIO
Description Wire Color
+5 VDC RED
LED 1 YEL-GRY
LED 2 YEL-VIO
LED 3 YEL-BLU
LED 4 YEL-GRN
