5.20 PLASTIC 13 ASSEMBLY

511-5930-13
ID Part Number Description
1 830-1156-13 PLASTIC, GODZILLA PRO, -13
2 520-7000-00 SINGLE FLASH LED BOARD
3 232-5202-00 SCREW, 6-32 X 1/2" PPH MS SEMS
4 242-5001-00 #6 WASHER
5 550-5510-02 HAT - TRIMMED - RED SB
6 240-5005-00 6-32 NYLON STOP NUT

5.21 PLASTIC 14 ASSEMBLY

511-5930-14
ITEM PART
NO. NUMBER
1 830-1156-13 PLASTIC, SPECTRE PRO, -13
2 520-7000-00 SINGLE FLASH LED BOARD
3 232-5202-00 SCREW, 6-32 X 1/2" PPH MS SEMS
4 242-5001-00
5 550-5510-02 HAT - TRIMMED - RED SB
6 240-5005-00 6-32 NYLON STOP NUT
ID Part Number Description
1 830-1156-14 PLASTIC, GODZILLA PRO, -14
2 237-5510-00 SCREW, 6-32 X 1-1/2" PPH MS
3 240-5005-00 6-32 NYLON STOP NUT
4 550-5034-01 GROOVED JEWEL PLASTIC POST, CLEAR 1
5 545-5348-03 3/8" I.D., BLACK RUBBER
ITEM PART
NO. NUMBER
1 830-1156-14 PLASTIC, SPECTRE PRO, -14
2 237-5510-00 SCREW, 6-32 X 1-1/2" PPH MS
3
4
1
5
2
6
Qty
1
1
1
1
1
1
DESCRIPTION
2
5
#6 WASHER
4
1
3
Qty
1
1
1
1
GODZILLA PRO MANUAL 500-55T5-01
DESCRIPTION QTY.
1
1

5.22 PLASTIC 16 ASSEMBLY

511-5930-16
ID Part Number Description
1 830-1156-16 PLASTIC, GODZILLA PRO, -16
2 237-6378-00 #6-32 X 3/8 PAN PHILLIPS w/DOUBLE SEMS 1
3 242-5001-00 #6 WASHER
4 254-5008-02 HEX SPACER - 5/8 "
ITEM PART
NO. NUMBER
1 830-1156-16
QTY.
2 237-6378-00
1
3 242-5001-00
1
4 254-5008-02
1
1
1
1
PARTS REFERENCE
4
3
1
2
DESCRIPTION
PLASTIC, SPECTRE PRO, -16
#6-32 X 3/8 PAN PHILLIPS w/DOUBLE
SEMS
#6 WASHER
HEX SPACER - 5/8 "
Qty
1
1
1
QTY.
1
1
1
1
