5.40 BALL GUIDE 06 ASSEMBLY

511-5933-06
3 2X
LOCTITE 243
ID Part Number Description
1 535-2659-06 BALL GUIDE, GODZILLA PRO, -06
2 511-5763-00 ASM, BALL GUIDE MNT SPINNER, RIGHT 1
3 237-6151-00 SCREW, 4-40 X 5/16" PFH U/C MS

5.41 BALL GUIDE 07 ASSEMBLY

511-5933-07
ITEM PART
NO. NUMBER
1 535-2659-06 BALL GUIDE, SPECTRE PRO, -06
2 511-5763-00 ASM, BALL GUIDE MNT SPINNER, RIGHT
3 237-6151-00 SCREW, 4-40 X 5/16" PFH U/C MS
4
ID Part Number Description
1 535-2659-07 BALL GUIDE, GODZILLA PRO, -07
2 237-6151-00 SCREW, 4-40 X 5/16" PFH U/C MS
3 535-9366-01 BUMPER HOLDER
4 626-5057-01 RUBBER BUMPER - BLUE
2
1
Qty
1
2
1
DESCRIPTION QTY.
3
2
Qty
1
2
1
1
GODZILLA PRO MANUAL 500-55T5-01

5.42 BALL GUIDE 12 ASSEMBLY

511-5773-12
4
3
ID Part Number Description
1 535-2477-12 BALL GUIDE, GODZILLA, -12
2 515-0215-00 LONG RANGE OPTO EMITTER ASSEMBLY
3 515-0215-01 LONG RANGE OPTO RECEIVER ASSEMBLY
4 237-5880-00 SCREW, #6 X 3/8 PPH T-25

5.43 BALL GUIDE 15 ASSEMBLY

1
511-5933-15
1
2
4
2
LOCTITE 243
2
ID Part Number Description
1 535-2659-15 BALL GUIDE, GODZILLA PRO, -15
2 237-6151-00 SCREW, 4-40 X 5/16" PFH U/C MS
3 626-5057-01 RUBBER BUMPER - BLUE
4 535-9366-01 BUMPER HOLDER
ITEM PART
NO. NUMBER
PARTS REFERENCE
1
2
1
3
DESCRIPTION QTY.
Qty
1
1
1
4
Qty
1
2
1
1
