5.34 LEFT ENTRANCE RAMP
ASSEMBLY
500-1161-00
5
4
QTY.
ES LE 1 12
2
2
10
8
1
5
5
5
1
S 1
ES 1
2
1
1
LE 1
1
S PRO 1
ID PartNumber Description
RO 1
1 510-7774-00 RIVETED ASSY, LEFT ENTRANCE RAMP,
2
STRANGER THINGS LE
.06 FT.
2 515-0215-00 LONG RANGE OPTO EMITTER ASSEMBLY
1
3 515-0215-01 LONG RANGE OPTO RECEIVER ASSEMBLY
4 237-5880-00 SCREW, #6 X 3/8 PPH T-25
5 510-7773-15 RIVETED ASSY, PLASTIC #15, STRANGER
THINGS LE
6 232-5202-00 SCREW, 6-32 X 1/2" PPH MS SEMS
7 242-5001-00 #6 WASHER
8 240-5005-00 6-32 NYLON STOP NUT
9 510-7773-20 RIVETED ASSY, PLASTIC #20, STRANGER
THINGS
10 535-2259-00 LEFT RAMP PROTECTOR, LEFT WALL,
STRANGER THINGS
11 535-2259-01 LEFT RAMP PROTECTOR, RIGHT WALL,
STRANGER THINGS
12 237-5809-00 SCREW, #6 X 1/2" PTH A
52
3
6
7
8
2
3
11
12
10
STRANGER THINGS PREMIUM MANUAL 500-55Y2-01
14

LEFT ENTRANCE RAMP ASSEMBLY

13
STRANGER THINGS LE / PREMIUM
500-1161-00
9
16
1
3
2
6
7
5
Qty 13 820-1107-81
1
14 820-1107-80
2
15 820-1107-88
2
4
8
16 510-7773-56
1
95* 820-1142-34
5
96* 820-1142-35
5
5
97* 820-1142-40
1
98* 605-5002-00
1
99* 040-5001-00B CABLE TIE 4" BLACK
16 510-7773-56
1
2
2
11
15
13
DECAL #81, LEFT RAMP FLOOR, STRANGER
THINGS LE
9
DECAL #80, LEFT RAMP WALL, STRANGER
THINGS LE
DECAL #88, LEFT RAMP PROTECTOR,
STRANGER THINGS LE
16
PLASTIC - GUIDE ROD REAR, CLEAR
DECAL #34, OPTO LEFT RAMP ENTER,
STRANGER THINGS PRO
DECAL #35, OPTO LEFT RAMP EXIT,
STRANGER THINGS PRO
DECAL #40, OPTO POWER, STRANGER
THINGS PRO
SHRINK TUBING 1/8" ID
8
PLASTIC - GUIDE ROD REAR, CLEAR
2
3
