4.10 1-RGB 5-W LED BOARD 9B

520-8536-00
ID Type Pin
CN1 .100" 4-Pin Header 1
2
3
4
CN2 .100" 7-Pin Header 1
2
3
4
5
6
7
CN3 .100" 8-Pin Header 1
2
3
4
5
6
7
8
CN4 .100" 6-Pin Header 1
2
3
4
5
6
Description Wire Color
+5 VDC RED
LED 6 -
LED 7 -
LED 8 ORG
Ground BLK
MISO Output Data VIO-BLK
MOSI Input Data VIO-BRN
SCK Serial Clock VIO-RED
RCK Register Clock VIO-ORG
NC -
+5 VDC IN RED
+5 VDC RED
+5 VDC RED
LED 10 BLU-RED
LED 11 BLU-ORG
LED 12 BLU-YEL
LED 13 ORG-BLU
LED 14 -
GND -
Ground BLK
MISO Output Data VIO-BLK
MOSI Input Data VIO-BRN
SCK Serial Clock VIO-RED
RCK Register Clock VIO-ORG
V+ RED
GODZILLA PRO MANUAL 500-55T5-01
ELECTRONIC PINOUTS AND SCHEMATICS
4.11 SW & LED BOARD 9C
520-8537-00
ID Type Pin
CN1 .100" 8-Pin Header 1
2
3
4
5
6
7
8
CN2 .100" 7-Pin Header 1
2
3
4
5
6
7
CN3 .100" 5-Pin Header 1
2
3
4
5
CN4 .100" 6-Pin Header 1
2
3
4
5
6
Description Wire Color
+5 VDC RED
+5 VDC RED
LED 1 -
LED 2 -
LED 3 -
LED 4 ORG-GRY
LED 5 ORG-WHT
LED 6 -
Ground BLK
MISO Output Data VIO-BLK
MOSI Input Data VIO-BRN
SCK Serial Clock VIO-RED
RCK Register Clock VIO-ORG
NC -
+5 VDC IN RED
+5 VDC -
+5 VDC -
LED 8 -
LED 9 -
LED 10 -
Ground -
MISO Output Data -
MOSI Input Data -
SCK Serial Clock -
RCK Register Clock -
V+ -
