5.46 BACKPANEL ASSEMBLY

500-2560-01
1
12
10
9
17
6
ID Part Number Description
1 525-9739-01 BACK PANEL, GODZILLA, PRO
2 535-2288-00 HANDLE, BACKPANEL
3 240-5204-00 #10-32 T-NUT
4 237-6362-00 10-32 x 3/4" HWH MS SERR
15
5 234-5000-00 SCREW, #6 X 3/8" HWH
6 511-5961-01 VAC FORM BUILDING ASM, GODZILLA
15 PRO, RIGHT
7 237-6331-00 SCREW, 4-40 X 1/4" PPH MS BLACK
8 530-1305-06 BRACKET - PLASTIC MTG - 85°
9 511-5930-67 PLASTIC ASM, GODZILLA PRO, -67
ITEM PART
NO. NUMBER
4
2
3
3
11
15
8
16
15
7
7
5
13 3X
15
6X
GODZILLA PRO MANUAL 500-55T5-01
