5.32 LEFT NARROW SPINNER
ASSEMBLY
511-7655-00
2
ID Part Number Description
1 535-0179-00 SPINNER BRACKET, SIDE MOUNT
2 515-7088-00 SPINNER TARGET, NARROW
3 180-5010-04 MICRO-SWITCH
4 535-6539-00 SWITCH BODY PROTECT PLATE
5 237-5937-02 SCREW, 2-56 X 1/2" HWH MS
5.33 LEFT WIDE SPINNER
ASSEMBLY
511-5786-00
2
ID Part Number Description
1 535-2550-00 SPINNER BRACKET, SIDE MOUNT, WIDE
2 515-7088-01 SPINNER TARGET, LARGE
3 180-5010-04 MICRO-SWITCH
4 535-6539-00 SWITCH BODY PROTECT PLATE
5 237-5937-02 SCREW, 2-56 X 1/2" HWH MS
ITEM PART
NO. NUMBER
1 535-2550-00 SPINNER BRACKET, SIDE MOUNT, WIDE
1
3
5
4
Qty
1
1
1
1
2
1
3
4
5
2X
LOCTITE 243
Qty
1
1
1
1
2
GODZILLA PRO MANUAL 500-55T5-01
DESCRIPTION
5.34 ROLLUNDER SWITCH
ASSEMBLY
511-7963-00
2
4
3
3
ID Part Number Description
1 535-2056-00 BRACKET, ROLLUNDER GATE, BG MNT
2 180-5087-00 SWITCH - GATE
3 237-5937-02 SCREW, 2-56 X 1/2" HWH MS
4 535-6539-00 SWITCH BODY PROTECT PLATE
5 535-2057-00 WIRE, ROLLUNDER GATE, BG MNT
5.35 BALL GUIDE SPINNER
ASSEMBLY
511-5763-00
ITEM PART
NO. NUMBER
1 535-2056-00 BRACKET, ROLLUNDER GATE, BG MNT
2 180-5087-00
3 237-5937-02 SCREW, 2-56 X 1/2" HWH MS
4 535-6539-00 SWITCH BODY PROTECT PLATE
5 535-2057-00 WIRE, ROLLUNDER GATE, BG MNT
3
ID Part Number Description
1 535-2434-00 BRACKET, BG MOUNT SPINNER, RIGHT HAND 1
2 180-5010-04 MICRO-SWITCH
3 515-7088-00 SPINNER TARGET, NARROW
4 237-5937-02 SCREW, 2-56 X 1/2" HWH MS
5 535-6539-00 SWITCH BODY PROTECT PLATE
QTY.
1
PARTS REFERENCE
1
5
Qty
1
1
2
1
1
DESCRIPTION QTY.
1
SWITCH - GATE
4
2
5
Qty
1
1
2
1
51
1
1
2
1
1
