PINBALL MACHINE
SERVICE AND OPERATION MANUAL
WARNING
IMPORTANT HEALTH WARNING: PHOTOSENSITIVE SEIZURES - A very small percentage of people may experience a seizure when exposed to
certain visual images, including flashing lights or patterns. Even people with no history of seizures of epilepsy may have an undiagnosed condition that
can cause "photosensitive epileptic seizures" due to certain visual images, flashing lights or patterns. Symptoms can include light-headedness, altered
vision, eye or face twitching, jerking or shaking of arms or legs, disorientation, confusion, momentary loss of awareness, and loss of consciousness or
convulsions that can lead to injury from falling down or striking nearby objects.
IMMEDIATELY STOP PLAYING AND CONSULT A DOCTOR IF YOU EXPERIENCE ANY OF THESE SYMPTOMS.
Stern Pinball machines are assembled in Melrose Park, Illinois, USA; each pinball machine has unique characteristics that make it a one-of-a-kind
American-made product. Each machine will have variations in appearance resulting from differences in the machine's particular wood parts, individual
silk screened art and mechanical assemblies. Stern Pinball has inspected each game element to insure it meets our quality standards.
© 2015 KISS Catalog, Ltd. Under License to Epic Rights.
Games configured for North America operate on 60 cycle electricity only. These games will not operate in countries with 50 cycle electricity (Europe
UK, Australia).
WWW.STERNPINBALL.COM - FACEBOOK.COM/STERNPINBALL
1-800-KICKERS - PARTS.SERVICE@STERNPINBALL.COM
KISS PRO
KISS PRO #500-55H1-01
MANUAL #780-50H1-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KISS PRO and is the answer not in the manual?

Questions and answers

Related Manuals for Stern Pinball KISS PRO

Summary of Contents for Stern Pinball KISS PRO

  • Page 1 IMMEDIATELY STOP PLAYING AND CONSULT A DOCTOR IF YOU EXPERIENCE ANY OF THESE SYMPTOMS. Stern Pinball machines are assembled in Melrose Park, Illinois, USA; each pinball machine has unique characteristics that make it a one-of-a-kind American-made product. Each machine will have variations in appearance resulting from differences in the machine’s particular wood parts, individual silk screened art and mechanical assemblies.

  • Page 2: Table Of Contents

    5.14 Slingshot Flash Assy- 04 ........37 5.15 Power Scoop ............. 38 5.16 Up-Post Vuk Assembly ........38 5.17 Pop Bumper Assembly ........39 5.18 Right Ramp Pro Assy ......... 40 © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 3: Setup And Moving

    PEOPLE ARE REQUIRED TO MOVE AND MANEUVER THE INSTRUCTIONS GAME. USE PROPER MOVING TOOLS REQUIRED EQUIPMENT AND EXTREME Your brand new Stern Pinball Machine is carefully packed for safety and security. • 5/8” Socket Wrench CARE WHILE HANDLING. For your safety, exercise caution and use •...
  • Page 4 NER NICKS, WHICH CAN CAUSE THE GLASS TO FAIL CATASTROPHICALLY. TAKE CARE TO STORE THE GLASS ON A SOFT, ROOM-TEMPERATURE SURFACE AND PREVENT THE CORNERS FROM BEING DAMAGED. © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.
  • Page 5 Play game: Check for satisfactory operation and adjust game volume (push the Red Buttons inside the Coin Door). If desired, perform any game diagnostics, game adjust- ments, and pricing settings at this time. © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 6: Transporting The Game

    2. REMOVE THE LEGS AND Securely strap the back box to the 10. Secure all loose parts and trans- port with a hand truck in the upright position. CAUTION © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 7: Maintenance

    KISS Playfield Decals Kit (Germany) 802-5000-H1-GER KISS Pro Cabinet Decal Left 820-66H1-01 • Verify latest game software is installed KISS Pro Cabinet Decal Left (Germany) 820-66H1-01G • Check flippers for excessive wear. Excessive flipper sloppi- KISS Pro Cabinet Decal Right 820-66H1-02...

  • Page 8: Spike System And Node Guide

    9V node bus power is disabled to all playfield components A Stern Pinball machine based on the SPIKE system will have at until the switch is closed. least two nodes networked together with the SPIKE node bus, a custom industrial pinball control bus that is designed around 2.4 SPIKE NODE ADDRESSES...

  • Page 9: Spike System Terminology

    SPIKE 32 Light and Switch Node Node 520-5322-00 pair technician, perform ALL work on your pinball machine with Trough Serial Opto Receiver Extension Extension 520-5345-00 the power disabled! © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 10: Light, Switch, And Driver Reference

    Lower playfield 520-6969-00 OFF-ON-OFF-OFF Upper Playfield 48V 8-Driver Node Upper playfield 520-6935-00 Star LED Extension Mid playfield 520-6970-00 OFF-ON-ON Upper Playfield S/L I/O Node Upper playfield 520-5322-00 © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 11: Driver Reference

    ORANGE ORANGE WHITE WHITE WHITE WHITE BLUE FILTER RED FILTER PURPLE FILTER GREEN FILTER ORANGE ORANGE COLOSSAL BONUS CLEAR AMBER Figure 3.2.1. Playfield top component view © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 12: Switch Reference

    520-5345-01 rx Trough 2 CN14 Playfield Opto 8a-SW-13 520-5344-00 tx 520-5345-01 rx Trough 1 CN14 Playfield Opto 8a-SW-14 520-5344-00 tx 520-5345-01 rx Continued on next page... © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.
  • Page 13 ORANGE WHITE WHITE WHITE WHITE BLUE FILTER RED FILTER PURPLE FILTER GREEN FILTER ORANGE ORANGE COLOSSAL BONUS CLEAR AMBER Figure 3.3.2. Playfield switch locations (top view). © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.
  • Page 14 CPU Node 0-SW-0 DIP 2 CPU Node 0-SW-2 DIP 3 CPU Node 0-SW-3 DIP 4 CPU Node 0-SW-4 DIP 5 CPU Node 0-SW-5 Continued on next page... © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 15: Light Reference

    11-LP-23 520-5307-00 Backstage Pass LT ORG BLK Playfield Feature White 11-LP-14 520-5307-00 Backstage Pass RT ORG BRN Playfield Feature White 11-LP-15 520-5307-00 Continued on next page... © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.
  • Page 16 ORANGE ORANGE ORANGE ORANGE WHITE WHITE WHITE WHITE BLUE FILTER RED FILTER PURPLE FILTER GREEN FILTER ORANGE ORANGE COLOSSAL BONUS CLEAR AMBER Continued on next page © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.
  • Page 17 Playfield Feature Green 10-LP-33 520-6970-00 RT Ramp Arrow-BLU CN14 Playfield Feature Blue 10-LP-34 520-6970-00 Super Targets CN14 Playfield Feature White 10-LP-16 520-6970-00 Continued on next page © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.
  • Page 18 135 Pfld GI White Upper CN13 BLU BLK Playfield/ G.I. Blue 10-LP-4 112-5034-08 Back Pnl BLK GRY 2 Digital RED Coin Door 1-LP-0 136 Coin Enable © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 19: Electronic Pinouts And Schematics

    SD CARD For system SD card. Note: only to be removed if instructed to by Switzerland Stern Service. Taiwan CR232 3V Lithium battery for game clock between power cycles United Kingdom Figure 3.4.2. Country code DIP switch settings. © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.
  • Page 20 Figure 4.1.1. Service switch wiring. Note that the Cabient Node must be present and CN10 and CN12 connected for the Coin Door Service Switches to function correctly. © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 21: Node 1 Cabinet

    *Varies by country model .100" 6-Pin Coin Enable/DBA Inhibit (-) Header Coin Enable/DBA Inhibit (+) Dollar Bill Ac- ceptor DBA 12V Coin 6 / DBA Credit Ground © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 22: Lower Playfield 48V 8-Driver Pinout Node 8

    8-SW-5 8-DR-5 Driver Return ORG-GRY 48V Driver Power GRY-ORG .156" 4-Pin Switch Ground BLK-GRN Header (Orange) 8-SW-2 Switch GRY-BRN 8-DR-2 Driver Return YEL-ORG 48V Driver Power © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 23: Node 9 Mid Playfield 8-Driver 48V Pinout

    Fuse 7A SB, 125V 9-DR-5 Driver Return ORG-BRN 48V Driver Power GRY-BLK .156" 4-Pin Header Switch Ground (Orange) 9-SW-2 Switch 9-DR-2 Driver Return 48V Driver Power © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 24: Node 10 Upper Playfield 8-Driver 48V Pinout

    10-SW-5 WHT-RED 10-DR-5 Driver Return 48V Driver Power .156" 4-Pin Switch Ground BLK-BLU Header (Orange) 10-SW-2 Switch WHT-VIO 10-DR-2 Driver Return YEL-RED 48V Driver Power GRY-BRN © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 25: Node 11 Upper Playfield 32-Light And Switch Pinout

    11-LP-20 Light Return ORG-YEL 11-SW-22 Switch Return 11-LP-21 Light Return ORG-GRN 11-SW-23 Switch Return PNK-VIO 11-LP-22 Light Return ORG-BLU Switch Ground BLK-RED 11-LP-23 Light Return ORG-VIO Ground © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.
  • Page 26 BRN-RED 11-LP-26 Light Return BRN-ORG 11-LP-27 Light Return BRN-YEL 11-LP-28 Light Return BRN-GRN 11-LP-29 Light Return BRN-BLU 11-LP-30 Light Return BRN-VIO 11-LP-31 Light Return YEL-BLK Ground © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 27: Dual Motor Driver

    AC Line Neutral In Earth Ground In DC Ground DC Ground DC Ground +48 V System Power +48 V System Power +48 V System Power © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights. PINOUT...

  • Page 28: Star Lower Playfield Grid Led

    LED61 BRN-YEL LED62 BRN-GRN LED63 YEL-BLU +5 VDC LED Supply .100" 6-Pin Header +5 VDC LED Supply LED39 BLU-BRN LED40 BLU-RED LED41 BLU-ORG LED42 BLU-YEL Ground © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 29: Power Distribution Board

    Slow Blow MDL 200-5000-05 Figure 4.13.1. Power Distribution Board 520-5343-00 pinout 220/240v (Europe, Australia, Slow Blow MDL 200-5000-01 Figure 4.14.1. Standard fuses for line connections, 120V and 240V © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 30: Parts Reference

    Figure 5.1.2. Rubber ring inner diameter sizing tool. Hold ring up to chart and read largest size on inside of ring. Dimensions are In- ner Diameter (ID) unless otherwise noted as Outer Diamter (OD). © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 31: Playfield Assemblies, Top

    19 511-7676-00 Paul Assembly 20 510-7534-01 Riveted Assembly Head Trough 21 550-5031-02 Mini Mars (Red) 22 550-5032-07 Hat (Orange) Figure 5.3.1. Major playfield assemblies, Top locations. © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 32: Playfield Assemblies, Bottom

    30Degree Eject assy 26-1200 500-6520-ND 30Degree Eject Switch 500-9965-00 Up-Post VUK 500-7144-03 Spinning Disk Assembly 9/10 9/10 9/10 9/10 14/15 Figure 5.4.1. Major playfield assemblies, Bottom locations. © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 33: Backbox Parts

    NYLON SPACER - BLACK - 3/8 OD X .175 ID X 1/4" 535-8081-01 SPEAKER GRILL 240-5008-00 6-32 KEPS NUT 242-5001-00 #6 WASHER 820-8369-H1 DECAL: SPEAKER PANEL, KISS PRO © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 34: Cabinet Parts

    22 545-5072-02 GRILL - SPEAKER / VENT 23 031-5007-01 SPEAKER, CABINET 8" ROUND, 4 OHM 24 545-5090-00 CASH BOX - PLASTIC 25 535-5013-03 CASH BOX COVER © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 35: Auto Launch Assembly

    CABLE TROUGH OPTOS 18 545-0762-00 FISCHE PAPER: AUTO-LAUNCHER Figure 5.8.1. Auto Launch Assembly 500-9818-00 bill of materials. Figure 5.9.1. Ball trough assembly - 500-9820-00 bill of materials. © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 36: Flipper Assembly, Left

    * Refer to game rubber chart for flipper rubber color and part number. Figure 5.11.3. Right flipper assembly 500-6543-82-ND bill of mate- rials. Figure 5.11.2. Left flipper assembly 500-6543-83-ND BOM © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 37: Sling Shot Assemblies

    NYLON SPACER - BLACK - 3/8 OD X .175 ID X 266-5020-00 COMPRESSION SPRING-CONICAL 5/8" Figure 5.12.3. Sling shot 500-9924-00, -01 bill of materials. 240-5005-00 6-32 NYLON STOP NUT © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 38: Power Scoop

    244-5001-00 #2 LOCK WASHER, SPLIT 605-5006-00 SHRINK TUBING 1/8" .083 FT. 240-5301-00 2-56 HEX NUT 036-6246-00 CABLE, GENERIC COIL W/ SWITCH 036-5544-01 3" CABLE GENERIC SWITCH © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 39: Pop Bumper Assembly

    #6-32 x 1-3/16" SPIRAL FIN SHANK SCREW Figure 5.17.3. 515-6549-04-ND Pop bumper bottom bill of ma- Figure 5.17.1. 515-6459-WN Pop bumper assy top bill of mate- terials rials © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 40: Right Ramp Pro Assy

    EXTENSION SPRING-NO LOOP 820-8380-34 DECAL SET - 34 830-7028-35A PAUL GUITAR 237-5833-00 SCREW, #4 X 5/8" PFH - BLACK 237-5840-00 SCREW, #4 X 1/2" PFH AB © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 41: Plastic Flash Assy - 05

    SCREW, 6-32 X 3/8" PPH MS SEMS ID Part Number Description 830-7028-10 BUTYRATE SET - 10 254-5008-12 HEX SPACER - 3/8 " 232-5200-00 SCREW, 6-32 X 1/4" PPH SEMS © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 42: Plastic Assembly - 11

    STAR BALL GUIDE - 04 237-5880-02 SCREW, #6 X 1/2 PPH T-25 515-0215-01 LONG RANGE OPTO RECEIVER ASSEMBLY 545-9815-00 OPTO SENSOR PROTECTOR 237-5880-02 SCREW, #6 X 1/2 PPH T-25 © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 43: Gene Head Assy

    #10-32 x 1/2 HWH NO SLOT SERR ZI 237-5840-00 SCREW, #4 X 1/2" PFH AB 10 242-5003-00 #10 FLAT WASHER - 1/2" O.D. X .062 THICK © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 44: Specifications

    Nominal Line Power Current rating for your line voltage. For example, a 15A 120V household circuit, 15/3 A (nominal current) = 5 games maximum. © 2015 KISS Catalog, Ltd. KISS PRO MANUAL #500-55H1-01 Under License to Epic Rights.

  • Page 45: Warranty

    Stern Pinball Inc (‘SELLER’) warrants only to the initial purchaser of its ever measures may be required to correct the interference.
  • Page 46 1-800-KICKERS KISS PRO MODEL #500-55H1-01 MANUAL PART #780-50H1-01 PARTS.SERVICE@STERNPINBALL.COM 07/07/15 EDITION WWW.STERNPINBALL.COM *780-50H1-01* FACEBOOK.COM/STERNPINBALL...
