Table 4. Jumper Default Settings - ST STM32U575I-EV User Manual

Table 4 describes the default jumper setting.
Jumper
JP1
JP2
JP3
JP4
JP5
JP6
JP7
JP8
JP9
JP10
JP11
JP12
JP13
JP14
JP15
JP16
JP17
JP18
JP19
JP20
JP21
JP22
JP23
JP24
JP25
JP26
JP27
JP28
JP29
JP30
JP31
JP32
JP33
JP34
JP35
JP36
UM2854 - Rev 1
Table 4.
Function
GND probe
GND probe
BOOTLOADER_BOOT0 from USART
VDDIO power source selection
VDD_USB source selection
5V_UCPD sink/source
5V_UCPD sink/source
5V_UCPD sink/source
USB_DBCC2
I2C / UART selection
I2C / UART selection
UART_CTS selection
USB_DBCC1
UCPD_FLT selection
UCPD_DBn
VDDSMPS_CIN power source selection
VDDA power source selection
VREFP power source selection
VDD_MCU IDD jumper
OCTOSPI2 CSn selection
Potentiometer / LDR selection
COMP / OPAMP selection
VDD power source selection
VBAT power source selection
5V power source selection
FDCAN transceiver STBY selection
FDCAN_TX selection
FDCAN termination resistor
FDCAN_RX selection
STPMS2 for power metering data connection
STPMS2 for Sigma-Delta data connection
STLK_NRST
GND probe
BOOTLOADER_RST from UART_DB9
TAMPER selection
GND probe
Jumper default settings
Setting
- GND probe
- GND probe
OFF Boot 0 from USART not connected
ON VDDIO connected to VDD_MCU
ON VDD_USB connected to 3V3
ON 5V_UCPD connected to TCPP03 SINK path
5V_UCPD not connected to TCPP01 SINK
OFF
path
5V_UCPD connected to TCPP03 SOURCE
ON
path
OFF USB_DBCC2 on PB14 not used
[1-2] I2C_SCL on PG7 selected
[1-2] I2C_SDA on PG8 selected
OFF UART_CTS not connected
OFF USB_DBCC1 on PB5 not used
ON UCPD_FLT on PB8 connected
OFF UCPD_DBn on PB9 not used
ON VDDSMPS_CIN connected to VDD_MCU
[1-2] VDDA connected to VDD_MCU
ON VREFP connected to VDD_MCU
ON VDD_MCU connected to VDD
OCTOSPI2_NCs on PI5 used for OCTOSPI
[1-2]
Flash Chip select
[2-3] LDR selected for COMP and OPAMP function
[2-3] OPAMP function selected
[1-2] VDD connected to 3V3
[1-2] VBAT connected to VDD
[1-2] 5V connected to 5V_STLK source
[1-2] Normal mode selected
OFF FDCAN_TX not connected to PB9
Termination resistor on the physical link not
OFF
connected
OFF FDCAN_RX not connected to PB8
ON STPMS2 data connected to MDF interface
OFF STPMS2 data not connected to MDF interface
OFF STLINK-V3E not in RESET mode
- GND probe
OFF RST from UART not connected
Tamper connected to TAMPER button.
[1-2]
Passive mode
- GND probe
STM32U575I-EV
Default board configuration
Comment
page 12/105
