Figure 32. Cn7 Stmod+ Connector Pinout - ST STM32U575I-EV User Manual

I/O
PA1
MFX_IO14
PA0
PA5
PE4
PF10
PB6
1. The default configuration is shown in bold.
Figure 32 shows the CN7 STMod+ connector pinout.
UM2854 - Rev 1
(1)
Hardware Setting
PA1 is used as PMOD_INT on STMod+ and shared with Pmod
ON/ON
TAMPER_KEY
SB71/R135
PA1 is not used as STMOD+_INT on STMod+.
OFF/OFF
PA1 can be used for Tamper_Key or motor control.
R134 ON
MFX_IO14 is used as STMOD+_RST on STMod+and shared with Pmod
ON PA0 is used as ADC on STMod+.
SB79
PA0 is not used as ADC on STMod+.
OFF
PA0 can be used for OpAmp or motor control.
ON PA5 is used as PWM on STMod+.
SB82
PA5 is not used as PWM on STMod+.
OFF
PA5 can be used for VBUS_SENSE.
ON PE4 is used as MDF1_SDIN3 on STMod+ shared with onboard MEMS.
SB105
PE4 is not used as MDF1_SDIN3 on STMod+.
OFF
PE4 can be used for SRAM-A20.
ON PF10 is used as MDF1_CCK1 on STMod+ shared with onboard MEMS.
SB55
PF10 is not used as MDF1_CCK1 on STMod+.
OFF
PF10 can be used for Motor control.
ON PB6 is used as MDF1_SDIN5 on STMod+ shared with onboard MEMS.
SB41
PB6 is not used as MDF1_SDIN5 on STMod+.
OFF
PB6 can be used for Motor control.
Figure 32.
Configuration
CN7 STMod+ connector pinout
STM32U575I-EV
STMod+ connector
™
