Fluidwell F Series Manual page 10

Page 10
How to enter the setup menu
When the setup menu is protected by a password, the F132-P asks for a password to access the
setup menu.
Action
1 Press the PROG/ENTER
key, for at least 7
seconds.
2 Wait for the main menu
PRESET to show.
How to navigate in the setup menu
The setup menu has different main menus and submenus to program the F132-P. For navigation,
the main menus and the submenus are identified with numbers (for the main menu: e.g. .; for the
submenu: e.g. 12.).
The STOP/► key and the PROG/ENTER key are used to navigate between the menus. The
explanation assumes that you are in the main menu PRESET.
Action
Press the STOP /► key
1
to select the next main
menu.
2 Press again to go to the
next main menu.
3 Momentarily, press the
PROG/ENTER key to
select the previous main
menu.
4 Press again to go to the
previous main menu.
The START/▲ key and the STOP/► key are primarily used to navigate between the submenus.
The explanation assumes that you are in the main menu PRESET. When you are:
• in the first submenu and you navigate to the previous submenu, the F132-P goes back to the
main menu PRESET.
• in the last submenu and you navigate to the next submenu, the F132-P goes back to the main
menu PRESET.
Action
1 Press the START /▲
key to select the
submenu.
Press the START /▲
2
key again to go to the
next submenu.
Press the STOP/► key
3
to select the previous
submenu.
Press the STOP/►key
4
again to go to the
previous submenu.
Result
• The SETUP indicator To
enter the setup menu
comes on continuously.
• The main menu PRESET
shows.
Result
• The main menu FLOW
RATE shows
• The main menu
OVERRUN shows.
• The main menu FLOW
RATE shows
• The main menu PRESET
shows
Result
• The submenu UNIT
shows.
• The submenu DECIMALS
shows.
• The submenu UNIT
shows.
• The main menu PRESET
shows
FW_F132P_v1901_02_EN.docx
Note that sometimes the submenu
name is shown on the upper line of
the display.
Remark
To enter the setup menu.
• The RUN indicator goes
off.
• The SETUP indicator
comes on.
Remark
-
-
-
-
Remark
-
-
-
This is normal behavior
because the submenu UNIT is
the first submenu of the main
menu PRESET.
