Figure 3-1: Top Level Terminal Menu - ADTRAN Express XL User Manual

Menu Path
Describes the current
position in the terminal
menu structure.
Left Pane
Lists available
menus.
Mode
Describes current
operating mode.
Loop Status
Displays current
status of ISDN line.
Navigation Help
Displays list of
B-channel Status
characters you can
Displays current status
use to navigate the
of each B channel.
terminal menus.
Press Control-Z.
Right Pane
Lists available submenus. Additional
submenus available through this pane
are indicated by the [+] and [DATA]
symbols.
System Time
Displays the cur-
rent time. See Date/
Time on page 35 for
details on setting
the time.
