The Express XL/XLT supports a command line interface. All menu options
are configurable and readable from the terminal mode. Additional commands
are also available.
Menu Commands
Every menu item in the menu structure can be accessed through the terminal
mode interface. Terminal commands are as follows:
top_menu sub_menu1 sub_menu2 ... config_item
Each config_item is entered as shown below.
TYPE:
string
password
IP address
Hex
enum
unsigned
date
time
date/time
activator
list
array
61200070L1-1
Terminal Mode Commands
ENTERED AS:
printable characters within double quotes
printable characters within double quotes
xx.xx.xx.xx (0..9) separated by '.'
xx:xx:xx:xx (0..9,a..f) separated by ':'
sub-string or [#index]
digits (0..9)
mm-dd-yyyy
hh:mm:ss
mm-dd-yyyy hh:mm:ss
read only
followed by index with first record being 1
followed by index with first record being 1
