19. If the call is successful, the Status column will read active . If not, make
sure the number(s) are correct or reference Chapter 4 on page 107 (the trou-
bleshooting chapter) before going on to the next step.
20. Once the call is up, the PC must generate a DHCP request to obtain the IP
parameters needed to get on the Internet. Refer to your PC's user manual
or help screen.
MULTIPROTOCOL ROUTING BETWEEN TWO LANS
Remote/Home Office Accessing the Corporate LAN
The following steps can be used to set up the Express XL/XLT on a remote
LAN to access a corporate or central LAN using demand dial and dynamic
bandwidth management.
1.
Connect the 10BaseT cable from the hub to the Express XL/XLT. Select
TO HUB on the Express XL/XLT back panel. The LI indicator should be
illuminated.
2.
Set the IP address and Subnet Mask assigned by the network administra-
tor in the Configuration/IP menu.
3.
For the Default Gateway , enter the IP address of the access server at the
remote site. This creates a default route in the IP routing table that will be
used with the dial-on-demand feature in the Express XL/XLT.
4.
Use the arrow keys to get to the Configuration/IPX menu. Set the Net-
work value to the IPX network supplied by the network administrator.
Set the Seed Status to Seed . Arrow left and save the changes with a y
when prompted.
5.
Move to the Configuration/Connection List . Use the arrow keys to move
the cursor over the Num column. Type I to insert a new entry.
6.
Move the cursor over the Description field and press Enter. A pop up
window appears in which to enter a name for this Connection List profile.
7.
Move the cursor over the Authentication menu and press Return. This
will place the authentication parameters into the right pane.
8.
Enter the username and password under Tx Username and Tx Password.
These items should be provided by the administrator at the site being
dialed.
9.
Use the down arrow to display the IP menu parameters in the right pane.
10. Move the cursor over the Route menu and press Return.
61200070L1-1
Express XL/XLT User Manual
Quick Startup Guide
3
