Chapter 3: Terminal Menu Operation and Structure
Tx Link Rate - Current actual data transmission rate
Rx Link Rate - Current actual data reception rate
Tx Comp Ratio - Current transmission compression ratio
Rx Comp Ratio - Current reception compression ratio
Call Sessions/Spanning Tree
Read security: 5
When Bridge mode and Spanning Tree mode are active, this reflects the cur-
rent state of the LAN and WAN ports. The following can appear:
Off - Appears when spanning tree mode is disabled
Disabled - Port is not connected (for WAN) or disabled in
configuration
Listening - Port is in the listening state
Learning - Port is in the learning state
Forwarding - Port is in the forwarding state with the following
possible properties:
root - is the root port
designated - is designated port
Blocking - Port is in the blocked
Status/ARP Cache
Read security: 5
This lists the contents of the Express XL/XLT's ARP table. All resolved cache
entries time out after 20 minutes. Unresolved entries time out in 3 minutes.
ARP Cache/IP Address - IP address used for resolving MAC address
ARP Cache /MAC Address - Ethernet address resolved
(0=no resolution)
ARP Cache/Time - Minutes since entry was first entered
92
Express XL/XLT User Manual
61200070L1-1
