Status/Bridge Table

Read security: 5
This lists the contents of the Express XL/XLT's bridge table.
Bridge Cache/MAC Address - Ethernet address for device learned
Bridge Cache/Port - Port device learned from: LAN, WAN0, or WAN1
Bridge Cache/TTL - Seconds until address is removed from table

Status/IP Routes

Read security: 5
This lists the contents of the Express XL/XLT's IP router table.
IP Routes /IP Address - Network or host destination address
IP Routes /Netmask - Network mask applied to the destination
address
IP Routes /Gateway - Host or router to receive this packet
IP Routes /Port - Port gateway is located on:
local - sent directly to the Express XL/XLT router
eth0 - Express XL/XLT's ethernet port
wan0 - Express XL/XLT's first PPP bundle
wan1 - Express XL/XLT's second PPP bundle
idle - non-connected or "spoofed" route used for dial-on-demand
IP Routes /Use - Number of times the Express XL/XLT has
referenced the route
IP Routes/Flags - Important tags associated with this route entry
H - route is a host route
G - route is a gateway route
D - route learned dynamically from RIP
I - route learned from an ICMP redirect
P - route is private and is not advertised with RIP
T - route is to a triggered port (updates only when table changes)
