Chapter 3: Terminal Menu Operation and Structure
Traps/Manager Name
Write security: 2; Read security: 4
This is the text string describing the name of the entry. It is intended for easy
reference and has no bearing on the SNMP trap function.
Traps/Manager IP
Write security: 2; Read security: 4
This is the IP address of the manager that is to receive the traps.
Management/Maint Port
The Express XL/XLT has an EIA-232 connector on the back of the unit. The
setup for that port is under this menu.
Maint Port/Password Protect
Write security: 0; Read security: 1
When set to No, the maintenance port is not password protected. When On
(def), the Express XL/XLT will prompt for a password upon startup.
Maint Port/Password
Write security: 0; Read security: 1
This is the text string that is used for comparison when password protecting
the maintenance port. By default, no password is entered.
The security level for the maintenance port is always set to 0. This gives full access to
all menus.
Maint Port/Baud Rate
Write security: 5; Read security: 5
This is the asynchronous rate that the maintenance port will run. The possible
values are 300, 1200, 2400, 4800, 9600 (def), 19200, 38400, 57600, 115200.
Maint Port/Data Bits
Write security: 5; Read security: 5
This is the asynchronous bit rate that the maintenance port will run. The pos-
sible values are 7 or 8 (def) bits.
86
Express XL/XLT User Manual
61200070L1-1
