A.2 Bus Loading
You must pay careful attention to bus loading when designing an interface to the
RCM2200. This section provides bus loading information for external devices.
Table A-2 lists the capacitance for the various RCM2200 I/O ports.
Table A-2. Capacitance of Rabbit 2000 I/O Ports
Parallel Ports A to E
Data Lines BD0–BD7
Address Lines BA0–BA12
54
I/O Ports
Input
Capacitance Capacitance
(pF)
12
10
4
Output
(pF)
14
12
8
