A.1 Electrical and Mechanical Characteristics
Figure A-1 shows the mechanical dimensions for the RCM2200.
2.300
(58.4)
1.060
(26.9)
J1
R2
D2
R7
U6
D1
Y1 C4
R8
R1 C17
R36
R37
RT1
C8
R9
D3
BT1
U1
U2
C28
R15
C12 R18
R17
Q2
C13 R21 R22 C14
R20 R16
R19
Y3
Q3 Q4
Q5
2.300
(58.4)
J5
NOTE: All measurements are in inches followed by millimeters enclosed in parentheses.
All dimensions have a manufacturing tolerance of ±0.01" (0.25 mm).
50
0.130 dia
(3.3)
U3 U8 U7
Y2 C2 C1
C7
J2
C30
JP2
C29 GND
JP5
JP1
JP6 GND
DS2
EGND
ACT
0.602
0.625
(15.3)
(15.7)
J4
1.600
(40.6)
Figure A-1. RCM2200 Dimensions
Please refer to the RCM2200
footprint diagram later in this
appendix for precise header
locations.
