Table A-1 lists the electrical, mechanical, and environmental specifications for the RCM2200.
Table A-1. RabbitCore RCM2200 Specifications
Parameter
Microprocessor
Ethernet Port
(10/100-compatible with
10Base-T interface)
Flash Memory
SRAM
Backup Battery
General-Purpose I/O
Additional Inputs
Additional Outputs
Memory, I/O Interface
Serial Ports
Serial Rate
Slave Interface
Real-Time Clock
Timers
Watchdog/Supervisor
Power
Operating Temperature
Humidity
Connectors
Board Size
52
RCM2200 RCM2210
RJ-45, 2 LEDs Raw signals only
One 256K
128K
Connection for user-supplied backup battery
(to support RTC and SRAM)
26 parallel I/0 lines grouped in five 8-bit ports (shared with serial ports):
• 16 configurable I/O
• 7 fixed inputs
• 3 fixed outputs
4 address lines, 8 data lines, I/O read/write
Four 5 V CMOS-compatible ports.
Two ports are configurable as clocked ports, one is a dedicated RS-232
programming port.
Maximum burst rate = CLK/32
Maximum sustained rate = CLK/64
A slave port allows the RCM2200 to be used as an intelligent peripheral
device slaved to a master processor, which may either be another Rabbit 2000
or any other type of processor
Five 8-bit timers cascadable in pairs, one 10-bit timer with 2 match registers
4.75 V to 5.25 V DC, 134 mA
Two IDC headers 2 × 13, 2 mm pitch
(41 mm × 59 mm × 22 mm)
RCM2250
®
Rabbit 2000 at 22.1 MHz
RJ-45, 2 LEDs
Two 256K
512K
2 startup mode, reset
Status, reset
Yes
that each have an interrupt
Yes
–40°C to +70°C
5% to 95%, noncondensing
1.60" × 2.30" × 0.86"
RCM2260
Raw signals only
Two 256K
512K
RabbitCore RCM2200
