Chapter 3. Terminal Menu Operation and Structure
NAVIGATING THE TERMINAL MENUS
General Layout
Menu Path
Moving Around
3-4
The following sections provide information on how to navigate through
the terminal menus.
When you first start a terminal mode session, the window shown in "Top
Level Terminal Menu" on page 3-2 displays. The screen is divided into left
and right panes. The left pane shows the current list of submenus, while
the right pane shows the contents of a selected submenu.
The top line of the display shows this session's current position (path) in
the menu tree. Figure 3-1 shows the top menu level with the cursor on the
Configuration submenu, so the path display shows Express 4110/Config-
uration.
Press Tab or the right arrow key to move the cursor from the left pane to
the right pane. Press Tab or the left arrow key to move the cursor from
the right pane back to the left pane. Use the up and down arrows to move
around within each pane. Press Enter to activate a menu. Press the left
arrow key or the Escape key to go back up the menu. The following
options display throughout the menus.
Submenus [+] or [DATA]
Menus that display [+] or [DATA] indicate that more items are available
when selected.
Activation Field <+>
Menus that display <+> indicate that an action is to be taken, such as acti-
vating a test.
Editable Data Field
A highlighted menu item indicates that you can enter data in that field.
Read-Only Field
An underlined field is a display field that contains read-only information.
Express 4100/4110 User Manual
61200176L2-1
