ST STR730-EVAL User Manual page 16

Connectors
Table 9.
Port
P0.13
P0.14
P0.15
P1.0
P1.1
P1.2
P1.3
P1.4
P1.5
P1.6
P1.7
P1.8
P1.9
P1.10
P1.11
P1.12
P1.13
P1.14
P1.15
P2.0
P2.1
P2.2
P2.3
P2.4
P2.5
P2.6
P2.7
P2.8
P2.9
P2.10
P2.11
P2.12
P2.13
P2.14
P2.15
16/29
STR730-EVAL board input/output summary (continued)
Peripheral
TP54
TP55
TP56
TP57
Test Point
Test Point
Test Point
Test Point
Test Point
Test Point
PIEZO (SW10-1)
PIEZO (SW10-3)
Test Point
Test Point
Test Point
Test Point
Test Point
CAN_RX (SW6-1)
CAN_TX (SW8-1)
BiColor LED - LD25
CAN_RX (SW6-3)
CAN_TX (SW8-3)
BiColor LED - LD23
BiColor LED - LD24
BiColor LED - LD21
BiColor LED - LD22
BiColor LED - LD17
UART_TXB
UART_RXB
SW_WAKEUP
Test Point
I2C_E1 / TP
I2C_E2 / TP
I2C_SCL
I2C_SDA
Alternate function
ICAPB3
OCMPB3
OCMPA3
OCMPA4
OCMPB4
ICAPB4
ICAPA4
OCMPB1
OCMPA1
OCMPA0
OCMPB0
CAN0RX
CAN0TX
PWM0
CAN1RX
CAN1TX
PWM1
PWM2
PWM3
PWM4
PWM5
UART1_TX
UART1_RX
SCL0
SDA0
UM0559
Interrupt
INT0
INT1
WUP28
WUP29
WUP30
WUP31
WUP12
WUP13
WUP14
WUP16
WUP17
INT14
INT15
