Table 9.
Port
P3.0
P3.1
P3.2
P3.3
P3.4
P3.5
P3.6
P3.7
P3.8
P3.9
P3.10
P3.11
P3.12
P3.13
P3.14
P3.15
P4.0
P4.1
P4.2
P4.3
P4.4
P4.5
P4.6
P4.7
P4.8
P4.9
P4.10
P4.11
P4.12
P4.13
P4.14
P4.15
P5.0
P5.1
P5.2
STR730-EVAL board input/output summary (continued)
Peripheral
10K_POT
LM35_THERM
Test Point
Test Point
Test Point
Test Point
Test Point
Test Point
Test Point
Test Point
Test Point
Test Point
Test Point
Test Point
Test Point
Test Point
LED_LD1
LED_LD2
LED_LD3
LED_LD4
LED_LD5
LED_LD6
LED_LD7
LED_LD8
LED_LD9
LED_LD10
LED_LD11
LED_LD12
LED_LD13
LED_LD14
LED_LD15
LED_LD16
TP7
TP6
TP5
Alternate function
AIN0
AIN1
AIN2
AIN3
AIN4
AIN5
AIN6
AIN7
AIN8
AIN9
AIN10
AIN11
AIN12
AIN13
AIN14
AIN15
ICAPA7
ICAPB7
ICAPA8
ICAPB8
SCL1
SDA1
OCMPA8
ICAPB6
ICAPA6
OCMPB8
ICAPA9
ICAPB9
nSS1
SCLK1
MOSI1
MISO1
OCMPA9
Connectors
Interrupt
INT2
INT3
INT4
INT5
WUP18
WUP19
WUP20
WUP21
WUP22
