UM0559
1

Introduction

STMicroelectronics is a global independent semiconductor company that designs, develops,
manufactures and markets a broad range of semiconductor integrated circuits and discrete
devices used in a wide variety of applications.
The STR730-EVAL board is based on the STR730FZ2T7, a highly integrated
microcontroller, running at up to 36 MHz that uses the popular ARM7TDMI
CPU featuring on-chip high speed single voltage flash memory and high-speed RAM, clock
generation via PLL, and numerous on-chip peripherals.
This board is intended as low cost development platform to demonstrate the capability of the
STR730 series of flash micro-controllers and to enable rapid evaluation of the STR730
devices and available peripherals.
The STR730-EVAL board has 8-Kbit SPI EEPROM and 8-Kbit I
CAN and RS232 interfaces. It includes a 2 x 16 programmable LCD display supported by
select, next, back, previous and wake-up push buttons.
The hardware platform of the STR730F series is supported by an extensive software
support package, including device drivers in ANSI C source form and demonstration
software. It is flashed with a demonstration application that shows the basic features of the
device. Development tools are readily available. This is complemented by a range of third
party real-time OS and middleware.
Design schematics can also be supplied in electronic format to those customers with
compatible design environments.
®
Note: ARM and ARM7TDMI
countries.
1.1

Processor and memory devices on this board

STR730F ARM7TDMI
–
–
–
–
–
Clocking is performed by a surface mounted 8 MHz quartz.
Serial ROMs:
–
–
TM
are registered trademarks of ARM Limited in the EU and other
TM
processor running at up to 36 MHz, IC11:
144-pin TQFP version,
256 Kbytes flash program memory,
16 Kbytes RAM,
embedded 1.8 V voltage regulator for core supply,
nested interrupt controller.
8-Kbit SPI EEPROM connected to the buffered serial peripheral interface (BSPI2):
IC7,
2
I C EEPROM: 8-Kbit EEPROM connected to the I
Introduction
TM
32-bit RISC
2
C EEPROM and supports
2
C0 interface: IC8.
3/29
