Setting method
① If the incorrect key is pressed or incorrect information is displayed during
setting, power must be shut off and the procedure started again.
② It is recommended that the settings are changed without supply pressure. The
product operates immediately maximum and minimum pressures are set and the
＜ＳＥＴ＞ key is pressed.
The minimum pressure is output when air is supplied to the inlet, even if the
③
input signal has not been entered.
Preset input type（ITV※0※※-4）
No Key operation
①
Unlock keys (refer to P11)
②
Press ＜ＳＥＴ＞ key
③
Set P̲1 by using the △ and ▽ keys.
④
Press ＜ＳＥＴ＞ key
⑤
Set P̲2 by using the △ and ▽ keys.
⑥
Press ＜ＳＥＴ＞ key
⑦
Set P̲3 by using the △ and ▽ keys.
⑧
Press ＜ＳＥＴ＞ key
⑨
Set P̲4 by using the △ and ▽ keys.
⑩
Press ＜ＳＥＴ＞ key
⑪
Lock keys (refer to P11)
△
CAUTION
！
⇔
Change the value by using △ and ▽ keys.
⇔
Change the value by using △ and ▽ keys.
⇔
Change the value by using △ and ▽ keys.
⇔
Change the value by using △ and ▽ keys.
Return to (current) pressure display.
―7―
LED Display
(displayed alternately)
(displayed alternately)
(displayed alternately)
(displayed alternately)
