Reset Function; Error Indicating Function - SMC Networks ITV1000 Series Operation Manual

Reset function
Reset method
No Key operation
① Unlock keys (refer to P11)
Press the △ and ▽
② simultaneously for 3 seconds or
more.
③
④ The setting is reset
Reset content
Item
F̲1
F̲2
P̲1、P̲2
P̲1〜P̲4
※ Gain (GL） and sensitivity (SL) are not reset.
Error indicating function
Error LED
No. display
１
２
３
４
５
Refer to the SMC website (URL http://www.smcworld.com) for more information about
troubleshooting.
This operation manual refers to all standard types and is partially applicable to special
models.
This operation manual is subject to change without prior notice or any obligation on the part
of the manufacturer.
Reset content
0%F.S.
100%F.S.
100%F.S.
0%F.S.
Contents of error
Input signal
rated value range.
Reading and writing errors
occurred in EEPROM.
Reading and writing errors
occurred in memory.
Solenoid valve failure.
Over current
output
keys
(Current) pressure is displayed
is displayed for approx. 1 second
Application model
Current・Voltage input type
Current・Voltage input type
Switch output type
Preset input type
Reduce input signal to within
exceeds the
the rated range and restart the
power supply.
Contact SMC.
Contact SMC.
Replace the solenoid valve.
For the replacement procedure
contact SMC.
Prevent over current errors by
errors in
ensuring the load meets the
specification.
―12―
LED Display
Countermeasure
ITV2-OM00068-C
