Setting Of Preset Pressure; Reset Function - SMC Networks ITV1000 series Operation Manual

Setting of preset pressure [Preset input type only]
No Key operation
①
Unlock keys (refer to P8)
②
Press S-key
③
Set P_1 by using the △ and ▽ keys.
④
Press S-key
⑤
Set P_2 by using the △ and ▽ keys.
⑥
Press S-key
⑦
Set P_3 by using the △ and ▽ keys.
⑧
Press S-key
⑨
Set P_4 by using the △ and ▽ keys.
⑩
Press S-key
⑪
Lock keys (refer to P11)
(Note): P_1 to P_4 are adjustable in a rrange from 0% to 100% of the rated value.
(DEFAULT VALUE: 0%)

Reset function

Reset method
No Key operation
① Unlock keys (refer to P11)
Press the
② simultaneously for 3 seconds or
more.
③
④ The setting is reset
Reset content
Item
F_1
F_2
P_1、P_2
P_1∼P_4
(Note): Gain (GL） and sensitivity (SL) are not reset.
△ and ▽
Reset content
0%F.S.
100%F.S.
100%F.S.
0%F.S.
⇔
⇔
⇔
⇔
Return to (current) pressure display.
keys
(Current) pressure is displayed
is displayed for approx. 1 second
Application model
Current・Voltage input type
Current・Voltage input type
Switch output type
Preset input type
