DEMO MANUAL DC1369A
parts List
ITEM
QTY
REFERENCE
1
1
C1
2
9
C2, C3, C6, C7, C38, C39, C59-C61
3
2
C10, C9
4
6
C12, C15, C18, C19, C21, C37
5
3
C13, C17, C23
6
2
C14, C22
7
1
C20
8
1
C24
9
12
C26-C36, C56
10
1
C51
11
2
C53, C52
12
2
C54, C55
13
7
R9, R10, R48, R54, R57, C57, C58
14
1
D1
15
3
JP2, JP3, JP4
16
3
J5, J7, J9
17
1
J8
18
1
L1
19
3
L2, L3, L4
20
1
L5
21
1
L6
22
1
P1
23
2
RN2, RN1
24
2
R1, R2
25
3
R4, R5, R56
26
1
R6
27
1
R7
28
1
R8
29
4
R14, R33, R34, R35
30
1
R16
31
8
R17-R23, R30
32
1
R24
33
3
R25, R26, R29
34
3
R36, R44, R45
35
2
R40, R39
36
0
R46, R49, R52, R53, R55
37
1
R47
38
1
R50
39
0
R51
40
5
TP1, TP2, TP3, TP4, TP5
41
1
T1
42
1
T2
8
PART DESCRIPTION
RES, 0402 150Ω 1% 1/16W
CAP , 0402 0.01uF 10% 16V X7R
CAP , 0402 8.2pF 5% 50V COG
CAP , 0402 0.1uF 10% 10V X5R
CAP , 0402 1uF 10% 10V X5R
CAP , 0603 1uF 10% 16V X7R
CAP , 0402 1uF 10% 10V X5R
CAP , 0603 4.7uF 20% 6.3V X5R
CAP , 0603 0.1uF 10% 50V X7R
CAP , 0402 4.7pF +/-0.25pF 50V NPO
CAP , 0402 100pf 5% 50V COG
CAP , 1206 22uF 10% 6.3V X5R
RES, 0402 0Ω JUMPER
DIODE, SCHOTTKY SOT-23
HEADER, 3-PIN, 2mm
CONN, BNC, SMA 50Ω EDGE-LANCH
HEADER, 2×7 2mm
IND, 0603 56uH 5%
FERRITE BEAD, 1206
IND, 0603 BEAD
IND, 0603 OPTION
EDGE FINGERS ON PCB
RES ARRAY, 33Ω
RES, 0402 301Ω 1% 1/16W
RES, 0402 OPTION
RES, 0402 10kΩ 5% 1/16W
RES, 0402 10kΩ 1% 1/16W
RES, 0402 6.81kΩ 1% 1/16W
RES, 0402 1kΩ 5% 1/16W
RES, 0402 100Ω 5% 1/16W
RES, 0201 100Ω 5% 1/16W
RES, 0402 100kΩ 5% 1/16W
RES, 0603 4.99kΩ 1% 1/16W
RES, 0402 86.6Ω 1% 1/16W
RES, 0402 24.9Ω 1% 1/16W
RES, 0402 OPTION
RES, 0402 20Ω 1% 1/16W
IND, 36nH
RES, 0402 301Ω 1% 1/16W OPTION
TURRETS
XFMR, 1:1
XFMR, 1:1 CT
MANUFACTURER/PART NUMBER
VISHAY CRCW0402150RFKED
AVX 0402YC103KAT
AVX 04025A8R2JAT2A
TDK C1005X5R1A104K
TDK C1005X5R1A105K
TDK C1608X7R1C105K
MURATA GRM155R61A105KE15D
TDK C1608X5R0J475MT
TDK C1608X7R1H104K
AVX 04025A4R7CAT2A
TDK C1005C0G1H101J
AVX 12066D226KAT2A
VISHAY CRCW04020000Z0ED
AVAGO HSMS-2822
SAMTEC TMM-103-02-L-S
E.F .JOHNSON, 142-0701-851
MOLEX 87331-1420
MURATA LQP18MN56NG02D
MURATA BLM31PG330SN1L
?
OPTION
PART OF THE PCB
VISHAY CRA04SS08333R0JTD
VISHAY CRCW0402301RFKED
OPTION
VISHAY CRCW040210K0JNED
VISHAY CRCW040210K0FKED
YAGEO RC0402FR-076K81L
VISHAY CRCW04021K00JNTDE3
VISHAY CRCW0402100RJNED
VISHAY CRCW0201100RFNTD
VISHAY CRCW0402100KJNED
AAC CR16-4991FM
VISHAY CRCW040286R6FKED
VISHAY CRCW040224R9FKED
VISHAY CRCW0402101J ?
VISHAY CRCW040220R0FKED
COILCRAFT 0402CS-36NXJB
VISHAY CRCW0402301RFKED OPTION
MILLMAX 2501-2-00-80-00-00-07-0
MACOM MABA-007159-000000
M/A-C0M MABAES0060/COILCRAFT WBC1-1LB
dc1369af
