Linear Technology DC1369A Demo Manual page 3

Ltc2262-14/-12, ltc2261-14/-12, ltc2260-14/-12, ltc2259-14/-12, ltc2258-14/-12, ltc2257-14/-12, ltc2256-14/-12, 14/12-bit, 25msps to 150msps adcs

Quick start proceDure

Analog Input

Parallel/Serial

Programming Mode

Duty Cycle Stabilizer

3.5V to 6V

SHDN

Single-Ended

Encode Clock

Figure 1. DC1369A Setup

DEMO MANUAL DC1369A

Jumpers Are Shown in

Default Positions

DC1369A F01

Parallel Data Output

to DC890

dc1369af
