Recording And Playback
•
Line 1 KHz, 6dBV Input
output1/2/3/4: 5dBV (2V) +/-2dB
tHD+n: less than 0.05% (W/20KHz lpf, a-WeIgHteD)
•
Phono 1 KHz, -41dBV Input
output1/2/3/4: 0dBV (1V) +/-2dB
tHD+n: less than 0.05% (W/20KHz lpf, a-WeIgHteD)
Maximum Input
(1 KHz, Master Output, THD=1%, EQ Flat, Maximum Gain)
•
line: more than +4dBV
•
phono: more than -36dBV
Maximum Output
(EQ Flat, Maximum Gain, THD=1%, Load=100K Ohm)
•
output 1/2/3/4: more than +6dBV (2V)
•
phones: more than +1.6dBV (1.2V) loaD=32 oHm
Mic Player Section
•
mic level: 10K ohm/-54dBV (out1/2/3/4:0dB (1V)+/-1dB)
•
mic tHD+n: less than 0.15%@1KHz (w/20kHz lpf, a-WeIgHteD)
•
mic S/n: more than 64dB
Note
The specifications are subject to change to any improvement by negotiations in
advance.
