5. CLUSTER IN FLOWN AND STACKED CONFIGURATION AND ACCESSORIES

• Types of installation other than those here described are not allowed.
• Never use the handles to suspend the speaker
• Always check that the positioning is stable and that the installation does not pose a danger to
people, animals or property.
• Perform the stacked installation on a flat, not tilted surface, otherwise an additional safety
fastening is mandatory.
The clusters of VIO C12 and VIO C15 allow one or two layers in both stacked and flown configuration, while those
of VIO C212 only one layer.
Below are indicated, as a summary, the flown configurations, the maximum number of speakers in mountable
clusters divided by model and accessory needed for hanging.
MODEL
VIO C12
VIO C15
VIO C212
A summary of the main accessories required to use VIO C clusters is shown in the table below.
NAME
CONNECTION FOR 2 OR MORE SPEAKERS IN CLUSTERS (THE NUMBER DEPENDS ON THE CONFI-
LP-1
GURATION)
DRK-C
FLYBAR FOR 2 SPEAKERS PER LAYER (MAX 4 VIO C)
DRKL-3
FLYBAR FOR 3 SPEAKERS PER LAYER (MAX 6 VIO C)
DRKL-4
FLYBAR FOR 4 SPEAKERS PER LAYER
DRK-CCA
FLYBAR IN VERTICAL INSTALLATION (MAX. 4 SPEAKERS)
RC-VIOC
RAIN COVER
The accessories for flown installation are described in detail on the following pages.
VIO C SERIES
34
DRK-C DRKL-3
2+2
2+2
2
DRKL-4
3+3
3+3
3
USE
DRK-CCA
4+4
4+4
4 NOT ALLOWED
